$3,049.00/Each

Ships free with Plus

Accessories & Options

Earn up to $91.47 back (9,147 points)with a Webstaurant Rewards Visa® Credit Card

  • Makes up to 350 lb. of half cube ice per day
  • Durable 304 stainless steel exteriors with polyethylene interiors
  • Digital controller allows user to quickly identify issues
  • Bright LED lights illuminate the ice bin
  • Kit includes ice machine, ice bin, and sanitary ice scoop
UPC Code:400015279765
Shipping:
Quick Shipping
Usually ships in 1 business day
Specs
Quantity1/Each
Width22 Inches
Depth32 11/16 Inches
Height67 11/16 Inches
Bin Width22 Inches
Bin Depth32 11/16 Inches
Bin Height45 5/16 Inches
Amps12 Amps
Hertz60 Hertz
Phase1 Phase
Voltage115 Volts
24 Hour Ice Yield 300 to 500 Pounds
Ambient Temperature Range40 - 90 Degrees F
Bin Storage Capacity275 lb.
BTU Per Hour2,696 BTU
Color Silver
Condenser Type Air Cooled
Ice Type Half Size Cubes
Installation Type Modular
Material Stainless Steel
Plug Type NEMA 5-15P
Power kWh/100 lbs. Ice5.1 kWh
Power Usage5.1 kWh per 100 lbs.
Refrigerant Type R-290
Type Ice Machines with Bins
Water Pressure Range18 3/4 - 80 PSI
Water Temperature Range40 - 90 Degrees F
Water Usage14.1 Gallons per 100 lbs.

Customer questions about this product

I haven’t heard of R-290, R-600a, R-513a, or R-448A refrigerant before. What is it?
R-290 (also known as high purity propane or CARE 40) and R-600a (also known as refrigerant grade Isobutane or CARE 10) are hydrocarbon refrigerants. R513a (also known as Opteon XP10) and R-448A (also known as Solstice N40) are HFO (hydrofluoroolefin) refrigerants. They are being used as an eco-friendly refrigerant by some manufacturers in response to the EPA’s Significant New Alternatives Policy (SNAP) Program. Read more about this program in our blog post on Refrigerant Regulations.
My ice machine has been shut down, or not in use since the COVID-19 shutdowns, how should I restart it?
If your ice machine has been shut down or not in use for a prolonged period time, please reference your machine's user-manual for a restart procedure, often called “Winterization." Please reference your user manual or contact customer service with any questions.
Does Avantco warrant this item for use in a food truck?
Avantco warrants new equipment sold to food truck customers to be operational for a period of 30 days from the date of delivery if installed and maintained correctly.
Why is a water filter automatically added to my cart with this item?
The use of poor quality feed water may void your equipment's warranty. Therefore, it’s important that your water be filtered to the highest quality and a compatible water filter will be included when you add this piece of equipment to your cart. You may remove the filter from the cart prior to purchase.
Ask your own question!

Details

Make sure you've always got plenty of fresh ice on hand with the Avantco Ice KMC-H-322-A 22" air cooled modular half cube ice machine with bin! Capable of producing up to 350 lb. of half cube ice per day, you'll always have plenty of ice to serve on demand. Not only that, with an included ice bin that holds an impressive 275 lb. of ice, this ice machine and bin duo are perfect for preventing periods of downtime while ice is being made. This kit also comes with an ice scoop for a complete set.

For ease of maintenance, a built in diagnostic system will identify problems that your ice machine may be having and will display the issue on the digital controller so it can be repaired accordingly. This easy-to-use controller can also be used to monitor the current stage of ice production that your machine is in. It allows you to adjust the bridge thickness up or down to maximize your harvest into individual cubes of ice, rather than full sheets. It also initiates the cleaning cycle and displays what stage of the cycle you're in.

Thanks to their durable type 304 stainless steel construction with polyethylene interiors, these units are built to last, and at only 30" in width, are great for kitchens where space is at a premium. Plus, (4) 6" adjustable legs stabilize the unit on uneven floors. A nickel plated evaporator and removable air filter make for quick and simple cleaning and maintenance. The ice machine comes with pre-drilled holes on the back of the unit to mount your OceanLoch water filter to the machine to ensure you are serving the cleanest and freshest ice possible. The ice machine is also designed for side-breathing and rear exhaust, which prevents hot air from being blown outward into your kitchen or service area. This unit requires a 115V electrical connection for operation.

Kit Includes:
- (1) Avantco Ice KMC-H-322-A 22" air cooled modular half cube ice machine - 350 lb.
- (1) Avantco Ice BIN23022 22"ice storage bin - 275 lb.

Ice Machine Dimensions:
Width: 22"
Depth: 24 3/8"
Height: 22 3/8"

Ice Bin Dimensions:
Width: 22"
Depth: 32 11/16"
Height: 45 5/16"

This Item Ships via Common Carrier. For more information and tips to help your delivery go smoothly, click here.

  • 5-15P

    5-15P

    This unit comes with a NEMA 5-15P plug.

  • 3/4" Water Connection

    3/4" Water Connection

    This unit comes with a 3/4" water connection.

  • ETL Sanitation

    ETL Sanitation

    This item meets the sanitation standards imposed by the ETL, a division of the Intertek Group.

Resources and Downloads

A PDF viewer is required to view this product's information. Download Adobe Acrobat software

Warranty Info

RESIDENTIAL USERS: Vendor assumes no liability for parts or labor coverage for component failure or other damages resulting from installation in non-commercial or residential applications.

Equivalent Items

Avantco 194KMC350B2H
Avantco KMC350B2H
