Scratch and Dent Avantco Ice KMC-F-530-LA 30" Air Cooled Modular Full Cube Ice Machine with 536 lb. Bin - 497 lb.

Item number  194kmcf530la

You are viewing a product from WebstaurantStore Outlet.

Condition:Outlet

Quick Shipping

Usually ships in 1 business day

Product Overview

  • Makes up to 497 lb. of full cube ice per day; Ice storage bin capacity 536 lb.
  • Durable roto plastic finish exterior with a polyethylene interior
  • Digital controller allows user to quickly identify issues and the current stage of production
  • Includes bright LED lights and a removable air filter
  • R290 refrigerant; 115V
  • Note: only the ice machine holds the ETL certification

This is an outlet item

Any warranty information listed in the manual is void unless otherwise stated and we will not be able to accept any returns.

Return Policy

Please note that all items are sold as is, and all sales are final. To ensure that each product in WebstaurantStore Outlet will work correctly upon arrival, it is tested by an experienced technician prior to shipping. We recommend that you carefully read the product description, damage/use description, and other related product literature such as specification sheets and product manuals before placing your order.

Please inspect each item carefully when it arrives at your place of business. If you observe any damage not detailed in the description on this website that may have been caused during shipping, do not sign for the delivery and contact us ASAP.

Cart Policy

Because Outlet items sell quickly on a first-come, first-serve basis, simply placing the item in your shopping cart for checkout at a later time does not guarantee a "hold" on the item.

Warranty Policy

Note that Outlet products are sold without any warranty. If you have any questions or concerns about a product even after reading the description and product literature, please contact us.

Specs

Quantity
1/Each
Shipping Weight
295 lb.
Width
30 1/2 Inches
Depth
34 Inches
Height
73 3/8 Inches
Bin Width
30 1/2 Inches
Ice Dispenser Width
30 1/2 Inches
Ice Machine Width
30 Inches
Bin Depth
34 Inches
Ice Machine Depth
24 3/8 Inches
Bin Height
51 Inches
Ice Machine Height
22 3/8 Inches
Amps
13.5 Amps
Phase
1 Phase
Voltage
115 Volts
24 Hour Ice Yield
497 Pounds
Ambient Temperature Range
40 - 90 Degrees F
Average Running Decibels
73 Decibels
Bin Storage Capacity
536 lb.
BTU Per Hour
3,798 BTU
Color
Silver
Condenser Type
Air Cooled
Drain Outlet Size
3/4 Inch
Exterior Material
Roto Plastic Finish
Features
LED Lighting
Ice Type
Full Size Cubes
Installation Type
Modular
Interior Material
Polyethylene
Plug Type
NEMA 5-15P
Power Usage
4.7 kWh per 100 lbs.
Refrigerant Type
R-290
Type
Ice Machines with Bins
Water Inlet Size
3/4 Inches
Water Pressure Range
18 3/4 - 80 PSI
Water Temperature Range
40 - 90 Degrees F
Water Usage
13.6 Gallons Per 100 lbs.

Scratch and Dent Details

  • New; never used
  • The brace behind front panel of ice maker is slightly bent
  • The bottom of the front panel is cracked
  • There are small scuffs and scratches on the ice bin

Make sure you've always got plenty of fresh ice on hand with the Avantco Ice KMC-F-530-LA 30" air cooled modular full cube ice machine with bin! Capable of producing up to 497 lb. of full cube ice per day, you'll always have plenty of ice to serve on demand at your restaurant, bar, or cafe. An included ice bin holds up to an impressive 536 lb. of ice, making it ideal for busy establishments that can not afford long periods of down-time while ice is being made. The ice bin features a durable roto plastic exterior with a polyethylene interior. Also included is an ice scoop, a scoop holder ledge just inside the door where the ice scoop leans, and a hook to hang it on for easy storage.

For ease of maintenance, a built-in diagnostic system will identify problems that your ice machine may be having and will display the issue on the digital controller so it can be repaired accordingly. This easy-to-use controller can also be used to monitor the current stage of ice production that your machine is in. It allows you to adjust the bridge thickness up or down to maximize your harvest into individual cubes of ice, rather than full sheets. It also initiates the cleaning cycle and displays what stage of the cycle you're in. Plus, the ice bin has a 3/4 FTP drain fitting.

The ice machine is constructed of durable roto plastic finish with a polyethylene interior to last in the busiest of commercial environments. A nickel plated evaporator and removable air filter make for quick and simple cleaning and maintenance. With (4) 6" adjustable legs, you can level your machine on uneven surfaces and have plenty of room to clean under it. This ice machine also comes with pre-drilled holes on the back of the unit to mount your OceanLoch+ water filter to the machine to ensure you are serving the cleanest and freshest ice possible. Designed for side-breathing and rear exhaust, you can avoid hot air being blown outward into your kitchen or service area. This unit requires a 115V electrical connection for operation.

Overall Dimensions:
Width: 30 1/2"
Depth: 34"
Height: 73 3/8"

Ice Machine Dimensions:
Width: 30"
Depth: 24 3/8"
Height: 22 3/8"

Ice Bin Dimensions:
Width: 30 1/2"
Depth: 34"
Height: 51"

Please check the Compatibility resource for information on items that work with this product.

This Item Ships via Common Carrier. For more information and tips to help your delivery go smoothly, click here.

Attention CA Residents:
  • 5-15P

    5-15P

    This unit comes with a NEMA 5-15P plug.

  • ETL Sanitation

    ETL Sanitation

    This product has been certified by ETL, a division of the Intertek Group, to meet applicable sanitation standards required for use in the United States and Canada.

  • ETL, US & Canada

    ETL, US & Canada

    This product has been certified by ETL, a division of the Intertek Group, to meet applicable electrical product safety standards required for use in the United States and Canada.

  • 3/4" Water Connection

    3/4" Water Connection

    This unit comes with a 3/4" water connection for water supply.
