CMA Dishmachines CMA-180-VL Single Rack High Temperature Ventless 3-Door Dishwasher - 208/240V, 1 Phase
Other Available Voltages:
- Eliminates need for vent hood
- Uses only 0.89 gallons of water per cycle
- Cleans up to 40 racks per hour
- Built-in 12 kW booster heater (40 degrees)
- 1 hp wash pump
- 208/240V, 1 Phase
White Glove Delivery - Available -What is White Glove service?
Standard common carrier delivery options cover the cost of getting an item to your shipping address but our White Glove delivery service does that and more!
The White Glove agent will call to schedule a Call Before Delivery within a four hour window, which gives you the flexibility to work around your busy schedule and to prepare the space where your item will be placed. Upon delivery, trained professionals will unload your large item from the truck, bring it into the room of choice, unpack the item and remove all packaging debris from the premises.
Please note that White Glove delivery will typically add 5 - 7 business days to your order's transit, and only includes 30 minutes of on-site time. If on-site time beyond 30 minutes is required, you may be responsible for additional fees. While the agents will bring the items into the location of your choice, this service does not include set-up of the items being delivered, such as installation of casters, shelves, or other accessories. Small items will not be unpackaged individually; they will be set in place and debris and packaging material will not be removed.
"You May Also Need" items are guaranteed to work with the item you are viewing, such as lids that will fit a cup or casters that will fit a piece of equipment. If an item is not listed in this section, we do not guarantee that it will work with the product you are viewing and do not recommend that you purchase them for use together.
Noble Chemical Acclaim 8 lb. / 128 oz. Solid Dish Machine Detergent - 4/Case
Noble Chemical Force X2 8 lb. / 128 oz. Solid Dish Machine Detergent - 2/Case
Noble Chemical Safe Block 8 lb. / 128 oz. Metal Safe Machine Warewashing Detergent - 4/Case
plus $82.99 /Case
Noble Chemical 8 lb. / 128 oz. Power Block Solid Dish Machine Detergent - 4/Case
Noble Chemical 8 lb. / 128 oz. Power Green Heavy Duty Solid Machine Dish Detergent - 4/Case
plus $98.99 /Case
Noble Chemical 1 gallon / 128 oz. Dry It Plus Rinse Aid for High Temperature Dish Machines - 4/Case
plus $98.99 /Case
Noble Chemical 5 Gallon / 640 oz. Dry It Plus Rinse Aid for High Temperature Dish Machines
plus $119.99 /Each
Noble Chemical 1 gallon / 128 oz. Dry It HD Premium Rinse Aid gallon / Drying Agent - 4/Case
plus $129.99 /Case
This video gives an overview on the features of the CMA 180 series dishwashers, with a focus on the CMA-180-VL ventless unit. It also covers some maintenance and usage tips, like how to repair a wash pump!
This video presents step-by-step instructions for installing your CMA 180 series dishwasher, and even goes over additional requirements you will need such as a 2" drain line. Check it out to learn more!
|CMA Dishmachines CMA-180-VL 208-240/1 Specs|
|Width||25 1/2 Inches|
|Height||86 5/16 Inches|
|Amps||78 - 88 Amps|
|Booster Heater Included||Yes|
|Booster Wattage||12 Kilowatts|
|Energy Star Qualified||Yes|
|High or Low Temp||High Temp|
|Interior Clearance||17 1/2 Inches|
|Made in America||Yes|
|Racks Per Hour||40|
|Wash Cycle Time||90 Seconds|
|Wash Tank Capacity||8 gal.|
|Water Inlet Size||1/2 Inches|
|Water Temperature||155 - 195 Degrees F|
|Water Usage||0.89 Gallons Per Rack|
Customer questions about this product
- Can this item fit through a standard height 80" doorway?
- Due to the height of this item, it may not be able to fit through a standard 80" tall doorway when standing upright. Please consider the best means of entry before purchasing, or measure your entryway to ensure that you will be able to bring your order inside if the item cannot be carried on its side.
CMA Dishmachines CMA-180-VL 208-240/1 Details
Thanks to its innovative ventless design, this CMA-180-VL single rack high temperature 3-door dishwasher cleans soiled dishware and glassware and saves on energy costs at the same time! This 3-door dish machine uses natural heat from the wash / rinse tank to preheat incoming final rinse water before it reaches the booster heater, lowering energy expenses and removing the need for an independent hood system at the same time. It is also designed to accept racks of dish and glassware through the front or sides for use in straight or corner applications, and it can wash up to 40 racks per hour with only 0.89 gallons of water per cycle! This dish machine also incorporates a soil purging system which traps plate debris in a removable external tray, keeping the wash water clean. A built-in 12kW booster heater is included.
- Ventless design with heat recovery system, for greater energy savings
- 6 kW wash tank heater
- Built-in 12kW booster heater (40 degrees)
- 8 gallon wash tank; 1 hp wash pump motor
- All stainless steel construction
- Fully automatic cycle for easy use; automatic heat exchange condenser wash-down
- It requires a 208/240V, 1 phase electrical connection
Width: 25 1/2"
Height: 86 5/16"
Inside Chamber Clearance: 17 1/2"
This Item Ships via Common Carrier. For more information and tips to help your delivery go smoothly, click here.
Because this item is not stocked in our warehouse, processing, transit times and stock availability will vary. If you need your items by a certain date,
please contact us prior to placing your order. Expedited shipping availability may vary. We cannot guarantee that this item can be cancelled off of the order or returned once it is placed.
This item meets the standards imposed by NSF International, which focuses on public safety, health, and the environment.
Made in America
This item was made in the United States of America.
Energy Star Qualified
This item has been Energy Star Qualified by the US Environmental Protection Agency and the US Department of Energy, making it an energy-efficient product.
UL US & Canada
This item has been tested and meets safety standards imposed by the Underwriters Laboratories (UL) for use in the United States of America and Canada.
This product must be hardwired; it does not plug into a standard wall outlet.
1/2" Water Connection
This unit comes with a 1/2" water connection.
