Located outside of the dishwasher, on the right hand side beneath the overflow shield is an external scrap tank, which will catch debris that is washed out during the final rinse. The dishes and utensils should be sprayed off after pre-scrapping is completed and before the rack is placed into the dishwasher. Remember, the better you pre-rinse, the better the wash results will be. The main drain for the wash tank and the scrap tank are both joined together, before they are connected to the building's main drain line. The use of a rubber connection boot is strongly recommended, along with two hose clamps, as seen here. Inside the wash tank is the heater element that runs the length of the tank, and just next to it, at the front of the tank, is the thermostat capillary and float switch. The thermostat control is located behind the front cover, just like the booster heater. The wash tank temperature should be set between 155 and 160 degrees Fahrenheit, while the booster heater should be set between 180 and 195 degrees Fahrenheit. The 1 hp wash pump is located at the bottom of the dishwasher and easily accessible for service. The motor is held in place with two main bolts to stabilize the motor and the wash pump intake. This will help stop possible leaking by the pump's intake and compression nut, with a heavy O-ring and slip ring used to prevent the compression nut from scraping the O-ring. Although the machine may be a single phase or three phase, the wash pump will always be a single phase motor. These very reliable wash pumps and motors are standard throughout the entire line of CMA's upright dishwashers and you can wire it for 220V, as shown in the model CMA 180 series here, or 110V, as seen in all of the CMA 180 series upright low temperature dishwashers. Starting at the front of the pump, remove the three bolts and one stud holding the wash pump housing to the pump base. The housing is sometimes also referred to as a snail, because of the shape. Now you can see the impeller. Remove the round cap on the back of the motor, which is covering the motor's drive shaft. Using a heavy flat or blade screwdriver, unscrew the impeller by turning it counterclockwise to prevent the motor from turning. CMA also has special removal tools available, one that can be used in the field, and one that can be used in the shop, and can be mounted to a bench. CMA also has a special removal tool available that can be used in the field. Once the impeller has been removed, You must then remove the spring, and then the graphite section of the pump kit. Then, remove the pump base to make removing the rear-facing ceramic seal section of the pump seal kit easier. To install the new pump seal kit, first re-install the pump base onto the pump motor. Then, using the food-grade silicone grease shown here, put the grease on both the motor shaft and the lower, rear-facing ceramic seal. CMA prefers this lubricant, part number 00206.35, that is available in small pillows which can cover one or two pumps. The rubber portion of the rear-facing ceramic seal goes on the pump base, where the white ceramic portion faces the graphite front portion of the seal kit. There is no special tool required to install the rear seal, however an old drain ball shaft, or piece of PVC that will fit over the motor shaft will work just fine. Then, the spring is installed before re-installing the impeller onto the motor shaft. Remember that the impeller is installed by turning it clockwise, to tighten it onto the shaft. The wash pump will always be turned clockwise, keeping the impeller tight on the motor shaft at all times. Since the wash pump assembly was dismantled, it will now need to be re-assembled. If you forgot how to install the pump seal kit, remember that it is packaged in the same order that it should be installed. Again, you should use the food-grade silicone lubricant to install the pump seals. This lubricant is also used when servicing other types of food equipment, such as ice cream machines. The pump seal lubricant is available from CMA in small field-use packaging. Use the CMA impeller removal tool when disassembling the wash pump. You will notice in the text below this part number, along with the part numbers for all of the pump components. The water inlet assembly is made up of a ball valve with a built-in line strainer. The new CMA-180T, or tall, is available in both a straight and corner configuration, and functions with the high-performance standards expected from a CMA dishwasher. However, this model only requires 93 1/2" of clearance to open the new split doors, instead of the previous 100" clearance required to open the original doors. Here, we have CMA's newest model, the CMA-180-VL, built with a new ventless option. The ventless option allows the dishwasher to perform excellently, using ambient cold water during its operation, resulting in clean, sparkling, and sanitized dishware and utensils. It will both a hot and cold water supply, however the hot water is only used to fill the dishwasher's wash tank and to flush or clean out the heat exchanger condenser. Hot water is supplied to both the water inlet valve that supplies the dishwasher's wash tank, and to the cleaning system for the heat exchanger condenser. The cold or ambient water is supplied directly to the inlet of the heat exchanger condenser at the top, while the water moves down through the condenser coils while the heat and steam rise. The steam condenses into water, and because it cannot be used, is discharged directly to the drain. The heat exchanger is now converting the ambient, or cold water, from 45 - 70 degrees Fahrenheit to 135 - 145 degrees Fahrenheit, to be supplied to the booster heater that will provide a 40 degree rise in temperature in 90 seconds. The total cycle time is 90 seconds, of which just 30 seconds is the steam evacuation time. The model CMA-180-VL, with the ventless option, comes in a three door configuration so it can be used as a straight pass-through, or a corner dishwasher. When the cycle light it lit, the doors can be raised, and a rack of dishes can be placed into the dishwasher. When the doors are lowered the cycle will begin. When the cycle light turns off, the rack can be removed, and another rack can be moved immediately into the dishwasher to start the next cycle, with the steam and heat passing through the heat exchange. The booster will consistently receive that 135 - 140 degree water - this is required to maintain the 180 degree plus water, while performing a 40 degree rise in water temperature in 90 seconds. The hot water valve is located at the top of the dishwasher, behind the control box and just in front of the condenser, with its own ball valve with a built-in line strainer to keep debris out of the dishwasher's plumbing system. Just past the water valve is the final rinse manifold for the chemical supplier's rinse injector for the rinse aid. The cold water valve, with its built-in line strainer, is located at the bottom of the dishwasher, with access from the front, as well as the left-hand side. The cold water valve supplies the condenser water which is then heated to 135 - 140 degrees Fahrenheit before feeding it to the booster heater. Now, let's look at the CMA 180 series installation check list. Check to make sure that your new dishwasher is level, after it was set in place. Check all electrical connections to ensure they are tight and secure. Check all water, drain, and plumbing connections for leaks; tighten if necessary. Check all wash arms to make sure they are installed correctly. Check final rinse arms to make sure they are installed correctly. Check that the wash tank temperature is a minimum of 155 degrees Fahrenheit. Check that the final rinse temperature is 180 - 195 degrees Fahrenheit. Check that the final rinse pressure is 20 PSI, plus or minus 5 PSI. Read all labeling and follow the instructions. Review the installation section before installing the model CMA 180 upright series dishwashers. All procedures and guidelines should be followed during installation. This concludes our installation and service training video. CMA dish machines - always delivering peace of mind.
Copy and paste the embed code above.
This video gives an overview on the features of the CMA 180 series dishwashers, with a focus on the CMA-180-VL ventless unit. It also covers some maintenance and usage tips, like how to repair a wash pump!
This video presents step-by-step instructions for installing your CMA 180 series dishwasher, and even goes over additional requirements you will need such as a 2" drain line. Check it out to learn more!
