How to install on G-Series 1-Section
Hi! Today i'll be showing you how to install our #4 trayslides into a G-Series single section. Before installing the new trayslides, we must first remove the shelves and shelf pins inside already.
After removing shelves and pins, go up and down the cabinet on the front and back panel using a flat head screwdriver - popping plugs out, revealing the screw holes for the pilasters.
Once the plugs have been removed, it's time to install the pilasters. There's two different sets of pilasters: one set is for the front left and back right and one set is for the front right and back left.
To determine which set you're looking at, take a look at the top cut-out of each pilaser. One has a very thin gap on top and one has a very tick gap on top. The thick gap should be on bottom for all of them.
After all the pilasters are installed, it's time to install the trayslides. In the #4 kit, there should be 4 pieces just like this to be installed.
After the trayslides have been installed, check to make sure your spacing ins correct.
Watch this video to learn how to install #4 Traulsen Trayslides on G Series 1-Section.
