This product is no longer available. We've left this page up for reference only.

Usually Ships in 12-15 Weeks from manufacturer

Lead times vary based on manufacturer stockEstimated shipping time tooltip

Product Overview

  • 80 lb. oil capacity
  • Innovative SMART4U controls
  • Five 6" diameter tubes
  • 125,000 BTU / hour
  • Stainless steel fry pot
  • Includes two fry baskets
  • Automatic basket lift
  • Natural gas
UPC Code:400011674922

Frymaster HD60GSBL NAT Specs

Shipping Weight
255 lb.
20 Inches
31 1/4 Inches
45 Inches
Fry Pot Width
18 Inches
Fry Pot Depth
18 Inches
Fry Pot Height
3 3/4 Inches
3 Amps
1 Phase
120 Volts
Burner Style
Stainless Steel
80 lb.
Basket Lifts

Made in America

NSF Listed

Programmable Controls
Gas Inlet Size
3/4 Inches
Number of Fry Baskets
Number of Fry Pots
Plug Type
NEMA 5-15P
Power Type
Natural Gas
Split Pot
Without Split Pot
Total BTU
125,000 BTU
Gas Floor Fryers

Customer questions about this product

My business is at a high elevation; does this change anything when I order gas cooking equipment?

Many gas equipment manufacturers need to make adjustments to the equipment so it operates correctly at elevations over 2,000 feet. Sometimes we can special order from the manufacturer and have your cooking equipment delivered ready-to-go, but in cases where your unit is in stock and waiting to ship, you’ll need to have a qualified service technician come to your location and alter your unit at the time of installation so that it is compatible with a higher elevation. Contact our Special Orders team prior to placing your order, and we will let you know what will work best for the equipment you are planning to purchase.

Is this cooking equipment available in all 50 states?

Due to energy regulations this cooking equipment is not available in all 50 states.

Ask your own question!

Frymaster HD60GSBL NAT Details

The ideal combination of efficiency and volume, the Frymaster HD60G-S natural gas 80 lb. Decathlon floor fryer is an excellent addition to any restaurant looking to increase profits from chicken tenders, French fries, and other popular fried foods! This tube type fryer has five 6" diameter tubes that provide 36% more surface area for heat transfer, resulting in extended oil life, low gas consumption, and less heat loss. And with its convenient basket lift, this fryer automatically removes your fry baskets from the oil after a set amount of time for maximum efficiency.

This fryer features innovative SMART4U 3000 controls that make it fast and easy to adjust any setting on your fryer. It can store up to 20 programmable functions so you can change cook times, temperatures, and more with the push of a single button, while its load compensation lets you produce large quantities of food while using 40% less oil. Individual tank readouts display information on cook cycles, programming values, and oil management to keep the operator informed at all times, promoting pinpoint accuracy when measuring oil temperature while allowing for high production and fast recovery times.

For easy cleaning and draining, this floor fryer has a wide cold zone with a 1 1/4" full port IPS ball-type drain valve and 3" drain line. The tank's bottom slopes forward to help collect and remove sediment from the fry pot, and this unit's front, sides, and doors are made of stainless steel for long-lasting durability.

- 125,000 BTU

- 18" x 18" x 3 3/4" fry area

- Electronic ignition

- Melt cycle and boil-out mode

- 6" steel legs

- 120V electrical connection required

Overall Dimensions:
Left to Right: 20"
Front to Back: 31 1/4"
Height: 45"

Please Note: For all orders shipping outside of the United States a 15% upcharge will be applied.

  • 3/4" Gas Connection

    3/4" Gas Connection

    This unit comes with a 3/4" gas connection to be installed by a professional.

  • Made in America

    Made in America

    This item was made in the United States of America.

  • CSA Design Cert

    CSA Design Cert

    This item has been certified by the Canadian Standards Association (CSA) and meets applicable U.S. standards.

  • NSF Listed

    NSF Listed

    This item meets the standards imposed by NSF International, which focuses on public safety, health, and the environment.

  • CSA Blue Flame

    CSA Blue Flame

    This item has been certified by the Canadian Standards Association (CSA) and meets applicable Canadian standards for appliances using gas or petroleum fuel.

  • 5-15P


    This unit comes with a NEMA 5-15P plug.

  • CSA_C_US


    This item meets the standards imposed by the Canadian Standards Association (CSA) for use in the United States of America and Canada.

Resources and Downloads for
Frymaster HD60GSBL NAT

A PDF viewer is required to view this product's information. Download Adobe Acrobat software

Warranty Info

Please note that this item is subject to a 15% export warranty administration fee for all international orders.
RESIDENTIAL USERS: Vendor assumes no liability for parts or labor coverage for component failure or other damages resulting from installation in non-commercial or residential applications. Your warranty will be voided if installed in non-commercial or residential applications.
