Name: Avantco UDD-36-HC-S 36" Stainless Steel Triple Tap Kegerator Beer Dispenser - (1) 1/2 Keg Capacity
Brand: Avantco Refrigeration
SKU: 178UDD36S3
Price: 2389 USD
Availability: InStock

0:00 / 0:00

Regularly

$2,389.00/Each

Plus Member Price

$2,239.00/Each

Ships free with Plus

Earn up to $71.67 back (7,167 points)with a Webstaurant Rewards Visa® Credit Card

Configuration: Triple Tap

Installation Services

Check if installation is currently available for your area.

Quick Shipping

Usually ships in 1 business day

Product Overview

Thick stainless steel countertop with stainless steel interior and exterior
LED interior lighting
Includes (3) "D" system couplers and keg mats
Two adjustable epoxy-coated steel shelves can be removed to fit one 1/2 keg
115V; 1/4 hp; R290 refrigerant

UPC Code:400016121575

View all Avantco Refrigeration Beer Dispensers

New & Improved Avantco Refrigeration Warranty. 2 Year Parts & Labor. 5 Year Compressor.

Quantity: 1/Each
Shipping Weight: 176 lb.
Width: 36 13/16 Inches
Depth: 24 3/8 Inches
Height: 35 5/8 Inches
Power Cord Length: 108 Inches
Interior Width: 24 1/4 Inches
Packaging Width: 39 1/8 Inches
Shelf Width: 23 3/5 Inches
Depth with Door Open: 49 Inches
Interior Depth: 18 1/2 Inches
Nominal Depth: Standard
Packaging Depth: 27 1/2 Inches
Shelf Depth: 17 9/10 Inches
Faucet Height: 10 1/4 Inches
Interior Height: 30 1/2 Inches
Packaging Height: 41 3/4 Inches
Tap Tower Height: 16 Inches
Tap Tower Diameter: 3 Inches
Amps: 3 Amps
Hertz: 60 Hz
Phase: 1 Phase
Voltage: 115 Volts
Wattage: 280 Watts
Capacity: (1) 1/2 Kegs 7.75 cu. ft.
Casters: Without Casters
Compressor Location: Left Side Mounted
Compressor Style: Side / Rear Breathing
Countertop Type: Stainless Steel
Door Style: Swing
Door Type: Solid
Exterior Finish: Stainless Steel
Features: LED Lighting Removable Magnetic Door Gaskets Self-Closing Doors
Horsepower: 1/4 HP
Individual Shelf Capacity: 88 lb.
Insulation Material: Polyurethane Foam
Material: Stainless Steel
Maximum Ambient Temperature: 90 Degrees F
Number of Doors: 1 Door
Number of Kegs: 1 Keg
Number of Shelves: 2 Shelves
Number of Taps: 3 Taps
Plug Type: NEMA 5-15P
Refrigerant Type: R-290
Shelf Material: Epoxy-Coated Steel
Starting Amps: 9 Amps
Starting Wattage: 840 Watts
Style: 1/2 Barrel
Temperature Range: 33 - 40 Degrees F
Type: Kegerators / Beer Dispensers

Details

Whether you operate a pub, banquet hall, catering service, or facilitate other special events, this Avantco UDD-36-HC-S 36" stainless steel triple tap kegerator beer dispenser is an excellent way to offer crisp, refreshing draft beer to your guests without investing in a complex built-in tap system! This unit features a triple tap tower with a 10 1/4" faucet height that allows you to easily fill pint glasses and pitchers with local microbrews, international macrobrews, and everything in between.

It holds (1) 1/2 keg and even comes with (2) 23 11/16" x 17 15/16" shelves for optional bottle or can storage. The epoxy-coated steel shelves are perfect for storing and organizing beverages for your bar service, from bottles of ale and beer to cans of crisp ciders. The solid door is not only self-closing to prevent potential energy loss, but also locks to prevent theft during off hours. This unit is equipped with knockout plugs to install external CO2 lines.

Unlike many competitive beer dispensers, this model ships with "D" system couplers so that you can tap kegs right out of the box! This commercial kegerator features a 201 type stainless steel interior and exterior, as well as a thick stainless steel top that is both durable and extremely simple to clean. A built-in drip tray further expedites end-of-day cleaning.

This unit has a 1/4 hp refrigeration system that circulates R290 hydrocarbon refrigerant. R290 refrigerant has an ozone depletion potential (ODP) of 0 and a global warming potential (GWP) of 3. A 115V electrical connection is required for operation.

Overall Dimensions:
Width: 36 13/16"
Depth: 24 3/8"
Height: 35 5/8"
Capacity: 7.75 cu. ft.

Interior Dimensions:
Width: 24 1/4"
Depth: 18 1/2"
Height: 30 1/2"

Tap Tower Dimensions:
Diameter: 3"
Height: 16"
Faucet Height: 10 1/4"

This Item Ships via Common Carrier. For more information and tips to help your delivery go smoothly, click here.

Attention CA Residents:

Customer questions about this product

Can this kegerator be used to dispense ciders?

No. Beverages such as cider, wine, and coffee have high levels of acidity, and dispensing them through this unit may damage its internal parts and have adverse effects on the product being dispensed. As designed, this unit is intended to dispense beer only. This model can be easily converted to be wine-safe, by swapping out the faucet, shank, beer hose, and coupler for stainless steel or wine-friendly equivalents.

Can this unit be used with an external CO2 tank?

Yes, the Avantco UDD2/3/4/48/60/72 have spots on the right-hand side opposite the compressor, while the Avantco UDD1 have spots in the back, where you can drill out holes for use with external CO2 lines.

Does Avantco warrant this item for use in a food truck?

Avantco warrants new equipment sold to food truck customers to be operational for a period of 30 days from the date of delivery if installed and maintained correctly.

Does this Avantco kegerator come with all of the accessories needed for operation?

While this unit does come with a coupler, you will also need a CO2 tank, CO2 regulator, and gas hoses.

Does this item ship to Canada?

This product cannot be shipped to Canada.

I haven’t heard of R-290, R-600a, R-513a, or R-448A refrigerant before. What is it?

R-290 (also known as high purity propane or CARE 40) and R-600a (also known as refrigerant grade Isobutane or CARE 10) are hydrocarbon refrigerants. R513a (also known as Opteon XP10) and R-448A (also known as Solstice N40) are HFO (hydrofluoroolefin) refrigerants. They are being used by some manufacturers in response to the EPA’s Significant New Alternatives Policy (SNAP) Program.

I'd like to install casters on this unit. Do I need 4 casters?

Yes, this item requires 4 casters. For convenience, we offer a kit with all of the casters and hardware required to mount them. See the Works With section.

What if my Avantco cooler doesn’t seem to be getting cold enough throughout the cabinet?

Make sure that you are loading it properly and not overloading it. This unit is designed for cans, bottles, and similar items that naturally enable good airflow within the cabinet. Overloading the cooler with cases and boxes will interrupt the airflow and negatively impact the unit’s performance.

What size CO2 tank do I need for this beer dispenser?

The size of the CO2 tank you choose will be determined by the size of your beer dispenser unit and how often you are willing to refill the tank. Larger tanks will last longer than smaller tanks, but frequency and usage should also be taken into consideration. If you plan to store your CO2 tank inside the beer dispenser, then size will be a factor here since you will also need enough room to properly store your kegs. Your local beer supplier will be able to offer suggestions and show you the maximum tank size for your dispenser.

Where are the included couplers for my beer dispenser?

The couplers for your unit may ship in the unit's packaging, or in separate packaging. Please check both to ensure they're all included!

Ask your own question!

5-15P
This unit comes with a NEMA 5-15P plug.
ETL Sanitation
This product has been certified by ETL, a division of the Intertek Group, to meet applicable sanitation standards required for use in the United States and Canada.
ETL, US
This product has been certified by ETL, a division of the Intertek Group, to meet applicable electrical product safety standards required for use in the United States.
