$4,684.00/Each

Contact us for details

Ships free with Plus

Call 717-392-7472(Mon - Thur: 5am - 12am EST
Fri: 5am - 8pm EST
Sat & Sun: 9am - 4pm EST)

Why do we do this?

Due to a manufacturer's price increase, this price will increase by 3.00% on 01/01/25

Earn up to $140.52 back (14,052 points)with a Webstaurant Rewards Visa® Credit Card

Installation Services

Check if installation is currently available for your area.

Usually Ships in 4 Weeks from manufacturer

Lead times vary based on manufacturer stock

Product Overview

  • Stainless steel front, sides, top, and drawers; corrosion-resistant aluminum interior
  • 2 drawers feature magnetic gaskets and telescoping slides; won't accidentally pull out of unit
  • Drawers won't accidentally pull out of unit and disrupt employee workflow
  • Full electronic control with an automatic defrost for easy operation and maintenance
  • Uses eco-friendly R290 refrigerant; 115V, 1/2 hp
UPC Code:400014093935

Beverage-Air UCFD36AHC-2-ADA Specs

Quantity
1/Each
Shipping Weight
218 lb.
Width
36 Inches
Depth
32 Inches
Height
33 5/8 Inches
Interior Width
32 Inches
Interior Depth
23 1/2 Inches
Interior Height
23 Inches
Amps
5.2 Amps
Hertz
60 Hz
Phase
1 Phase
Voltage
115 Volts
Access Type
Drawers
Capacity
8.7 cu. ft.
Compressor Location
Rear Mounted
Compressor Style
Side / Rear Breathing
Features
Made in America
Freezer Temperature
0
Horsepower
1/5 HP
Number of Drawers
2 Drawers
Plug Type
NEMA 5-15P
Refrigerant Type
R-290
Style
ADA Height
Type
Freezers  Undercounter Freezers

Beverage-Air UCFD36AHC-2-ADA Details

This Beverage-Air UCFD36AHC-2-ADA 36" undercounter freezer is a great solution when you need to increase the usable frozen storage capacity in your kitchen! With a stainless steel front, sides, top, and drawer design, this unit can stand up to the rigors of even fast-paced kitchens, and since the interior liner is made from aluminum, you won't need to worry about rust and corrosion compromising the safety of the food you serve.

The drawers hold 6" deep food pans (sold separately) and are supported by telescoping drawer slides with stainless steel roller bearing wheels, which allow for easy access. These slides also include a locking mechanism to prevent the drawers from inadvertently being pulled out of the cabinet. Magnetic gaskets ensure a tight seal when the drawers are closed.

With CFC and HCFC-free cabinet insulation, the cabient provides superior energy efficiency and temperature retention. This unit runs on eco-friendly R-290 refrigerant, which has an ozone depletion (ODP) of 0 and a global warming potential (GWP) of 3, making it an environmentally-responsible choice for your business. Thanks to a full electronic control you can also keep better track of the cabinet temperature and make sure it is at 0 degrees Fahrenheit or below for optimum food safety. A set of 4" casters (2 with brakes) makes it easy to move the unit for cleaning and maintenance. This model requires a 115V electrical connection.

Overall Dimensions:
Width: 36"
Depth: 32"
Height: 33 5/8"
Capacity: 8.7 cu. ft.

Interior Dimensions:
Width: 32"
Depth: 23 1/2"
Depth (Usable): 15 3/8"
Height: 23"

This Item Ships via Common Carrier. For more information and tips to help your delivery go smoothly, click here.

Because this item is not stocked in our warehouse, processing, transit times and stock availability will vary. If you need your items by a certain date, please contact us prior to placing your order. Expedited shipping availability may vary. We cannot guarantee that this item can be cancelled off of the order or returned once it is placed.

Attention CA Residents:

Customer questions about this product

Does Beverage-Air warrant this item for use in a food truck?

This item is covered under Beverage-Air's warranty contingent upon the unit being kept in a controlled climate. This means that the interior of the food truck may not be susceptible to extreme high or low temperatures. If warranty service is required, the truck must be able to sit stationary for 24-48 hours to allow for a technician to service the equipment.

How do I know if this unit will fit under or match the height of my ADA-height counter?

Many manufacturers offer their refrigeration equipment in several different height options to best meet your needs. Here's a breakdown of how we classify these different heights:

Counter Height: Work surface is more than 34" high; standard-height unit.

ADA Height: Work surface height is 34" or less; complies with ADA regulations.

Low Profile: Work surface height is less than 32"; designed to fit under most ADA-height counters.

If the unit you are purchasing does not have a flat top, such as a worktop or sandwich/salad prep table, it may affect whether or not it will align with certain countertops. To ensure that the product will meet your needs, please reference the product's literature and specifications.

I haven’t heard of R-290, R-600a, R-513a, or R-448A refrigerant before. What is it?

R-290 (also known as high purity propane or CARE 40) and R-600a (also known as refrigerant grade Isobutane or CARE 10) are hydrocarbon refrigerants. R513a (also known as Opteon XP10) and R-448A (also known as Solstice N40) are HFO (hydrofluoroolefin) refrigerants. They are being used by some manufacturers in response to the EPA’s Significant New Alternatives Policy (SNAP) Program.

What does the “H” or “HC” mean in the newer Beverage-Air model numbers?

This is a representation that the unit is using a “Hydrocarbon” refrigerant. This would include both R290 and R600a refrigerants. They are being used as an eco-friendly refrigerant by Beverage-Air in response to the EPA’s Significant New Alternatives Policy (SNAP) Program. Read more about this program in our blog post on Refrigerant Regulations.

Why is there a step in the interior of this undercounter unit?

This unit’s refrigeration system is located in the lower rear of the cabinet, causing the step in its interior. The step may decrease the inner depth of the cabinet's lower interior versus what is listed as its overall interior depth, so please check the unit’s specs and diagrams to ensure it will accommodate your storage needs.
Ask your own question!
  • Made in America

    Made in America

    This item was made in the United States of America.

  • UL Classified EPH

    UL Classified EPH

    This product has been certified by the Underwriters Laboratories (UL) to meet applicable ANSI/NSF standards and / or other food equipment hygiene codes and requirements.

  • 5-15P

    5-15P

    This unit comes with a NEMA 5-15P plug.

  • UL Listed, US & Canada

    UL Listed, US & Canada

    This product has been certified by the Underwriters Laboratories (UL) to meet applicable safety standards required for use in the United States and Canada.

  • UL Sanitation

    UL Sanitation

    This item has been tested and meets the sanitation hazard standards imposed by the Underwriters Laboratories (UL).

Need Parts & Accessories?

Show replacement parts and accessories for Beverage-Air UCFD36AHC-2-ADA today!

Resources and Downloads for
Beverage-Air UCFD36AHC-2-ADA

A PDF viewer is required to view this product's information. Download Adobe Acrobat software

Warranty Info

Note: Beverage Air equipment purchased in 2013 or later will have a 3 year parts and labor warranty. Equipment purchased prior to 2013 will have a 1 year parts and labor warranty. RESIDENTIAL USERS: Your warranty will be voided if installed in non-commercial or residential applications.
