Hobart PW10N-BAS-1 10-Pan High-Temperature Split-Door Pot, Pan, and Utensil Washer with Booster Heater - 208/240V, 3-Phase
$24,678.50/Each
Contact us for details
Call 717-392-7472Mon - Fri 8AM - 8PM EST
Earn up to $740.36 back (74,036 points)with a Webstaurant Rewards Visa® Credit Card
Product Overview
- Fits 10 full-sized sheet pans or (1) 140 qt. mixing bowl
- Features 2-, 4-, and 6-minute wash cycles
- Easy to operate with touchscreen controls and the SmartConnect app
- Sense-A-Temp booster increases the water temperature by 70 degrees Fahrenheit
- Includes 1 flat grid, 1 flat bottom rack, and 1 tray rack
- Quantity
- 1/Each
- Shipping Weight
- 550 lb.
- Width
- 37 3/16 Inches
- Depth
- 32 3/16 Inches
- Height
- 78 Inches
- Dishwasher Height
- Tall
- Amps
- 49.2 - 54.5 Amps
- Hertz
- 60 Hz
- Phase
- 3 Phase
- Voltage
- 208/240 Volts
- Application
- Pots & Pans Washers
- Booster Wattage
- 16.4 Kilowatts
- Capacity
- 10 Full Size Sheet Pans
- Dishwasher Style
- Front Load
- Door Style
- Split
- Features
- Booster Heater Included Energy Star Qualified Made in America NSF Listed
- High or Low Temp
- High Temp
- Horsepower
- 4 hp
- Minimum Water Inlet Temperature
- 110 Degrees F
- Number of Cycles
- 3 Cycles
- Plug Type
- Hardwire
- Racks Per Hour
- 20
- Type
- Single Rack Ventless
- Wash Cycle Time
- 120 - 360 Seconds
- Wash Tank Capacity
- 21 gal.
- Water Inlet Size
- 3/4 Inches
- Water Temperature
- 150 - 180 Degrees F
- Water Usage
- 1.2 Gallons Per Cycle
Hobart PW10N-BAS-1 Details
Ensure all your pots, pans, and utensils are cleaned thoroughly with this powerful Hobart washer. This machine reduces operating costs and saves time and money when cleaning a high volume of prep ware. It comes with a Sense-A-Temp booster heater that increases the water temperature by 70 degrees Fahrenheit, ensuring proper sanitation. It comes with 1 flat grid, 1 flat bottom rack, and 1 tray rack. Its spacious chamber fits 10 full-sized sheet pans or (1) 140 qt. mixing bowl. This dishwasher offers 2-, 4-, and 6-minute cycles to perform as many as 20 cycles per hour. It uses only 1.2 gallons of water per cycle, and it cleans as many as 200 sheet pans per hour.
This dishwasher is easy to operate with user-friendly touchscreen controls and WiFi connectivity. It works with the SmartConnect app to remotely access the machine status, error code reporting, temperature logs, and usage analysis. This unit boasts a pumped rinse system to boost water pressure and provide efficient rinsing of dishes and glassware. It also has a pumped drain to remove wash and rinse water at the end of each cycle. Its delime cycle eliminates hard water deposits that can cause damage to this dishwasher, making it easy to maintain and keep clean.
This dishwasher allows for scheduled fill and drain times, and it provides temperature alerts and lockouts. Plus, it offers convenient service diagnostics. It is made of durable stainless steel with a front-loading, split-door configuration and a deep-drawn tank. It features X-shaped, revolving upper and lower anti-clogging wash arms and revolving upper and lower rinse arms that are easily interchangeable. This dishwasher also comes with an external rack holder and a removable stainless steel scrap basket and strainer pans. It requires a 208/240V, 3-phase electrical connection for operation.
Overall Dimensions:
Width: 37 3/16"
Depth: 32 3/16"
Height: 78"
Height (with Door Open): 95 1/4"
This Item Ships via Common Carrier. For more information and tips to help your delivery go smoothly, click here.
Because this item is not stocked in our warehouse, processing, transit times and stock availability will vary. If you need your items by a certain date, please contact us prior to placing your order. Expedited shipping availability may vary. We cannot guarantee that this item can be cancelled off of the order or returned once it is placed.
3/4" Water Connection
This unit comes with a 3/4" water connection for water supply.
NSF Listed
This item has been certified by NSF International to meet applicable product standards on public safety, health, and / or the environment.
UL Listed, US & Canada
This product has been certified by the Underwriters Laboratories (UL) to meet applicable safety standards required for use in the United States and Canada.
Energy Star Qualified
This item has been Energy Star Qualified by the US Environmental Protection Agency and the US Department of Energy, making it an energy-efficient product.
Made in America
This item was made in the United States of America.
Hardwired
This product must be hardwired by a professional; it does not plug into a standard wall outlet.
