$539.00/Each

Ships free with Plus
  • Intuitive LCD display with Body Mass Index feature, Mother/Baby function, battery level indicator, and lock
  • Height rod measures 24" - 87 1/2" in 1/8" increments
  • Extra-large 17" x 17" platform with lift-off cover for cleaning and battery replacement
  • Standard with 1 RS232 serial and 1 micro USB-B port
  • Requires 12 AA batteries (sold separately)
UPC Code: 809161197808
Shipping:
Detecto Clinical Scales

Detecto Clinical Scales

Apex clinical scales: the Apex of patient measurement efficiency and stylish design. Dual integrated wheels. Available with mechanical or sonar height rods. Sonar touchless height rod measures 24" (2') - 86" (7' 2") or 60 cm - 218 cm. Extra wide platform measure 17" W x 17" D x 2.75" H (43.2 cm W x 43.2 cm D x 7 cm H). Capacity: 600 lb. x 0.2 lb. (300 kg x 0.1 kg). Body mass index calculation. High-tech weight indicator: 0.75" high, clinical-blue LCD weight readouts. Set to kilograms or pounds before initial use - metric lockout available. Automatically locks on weight temporarily. Weight and height displayed onscreen simultaneously. Battery power level indicator. Versatile connectivity: 1 micro USB-B port, 2 RS232 serial ports, HL7 IEEE 11073 compliant (standard). Also available: WiFi. AC adapter included with select models. Lift-off platform (12 AA batteries). Simple BMI calculation using mechanical height rod: stand on the scale, raise the height rod, enter height, press the BMI key.

Copy and paste the embed code above.

Make height and weight measurements easy and accurate with Detecto Apex clinical scales. These stylish and efficient scales offer convenient features that make taking measurements simple.

Detecto: Calibration Instructions

Detecto: Calibration Instructions

Detecto. This video will explain how to calibrate the weight on the Detecto Apex digital clinical scale. Before starting calibration, you should look at the capacity label on your scale's digital display. It will show you the capacity, interval, the division size or weight reservation, and weighing units either lb. or kg. To perform calibration, you will need certified test weights- a minimum of 50% of the scale's capacity, although 70%-100% is recommended in lb. or kg. depending on the weighing unit selected for your scale. During calibration, it is necessary to enter values using the scales keypad. When a prompt and value are displayed, press the enter key to save the display setting and proceed to the next prompt. To change the setting, press the up or down arrow keys to scroll through the available settings. When the desired setting is displayed, press the enter key to save it and advance to the next prompt. Note that when entering the scale capacity and calibration load values, pressing and holding the arrow keys allow you to increase or decrease the setting value. While in set-up, the prompts will be shown in the smaller upper segment display, with the setting values shown in the large lower seven segment display. Note that when moving through the set-up prompts, the default or previously selected value appears first on the display. To begin calibration and set-up, press the on/off key to turn the scale on. The scale will turn on all segments and enunciators to test the display, and then change to show the software version. With the software version showing on the display, press and hold the 0 key. The display will change to show CAP in the smaller upper seven segment display, the current scale capacity setting, and the large lower seven segment display and turn on the calibration enunciator. You are now ready to perform calibration. With the display showing CAP and the current capacity setting, press the enter key if the current setting is 600.0 lb. or 300.0 kg. Otherwise, press the up or down arrow keys until the display showing 600 lb. or 300 kg. and press the enter key. With the display showing INT in the current interval setting, press the enter key if the setting is 2 in lb. or 1 in kg. Otherwise, press the up or down arrow keys until the display is showing 2 of lb or 1 for kg and press the enter key. With the display showing DEC, and the current decimal point position setting, press the enter key if the setting is one, for weight in both lb or kg. Otherwise press the up or down arrow keys until the display is showing 1 for the decimal point position and press the enter key. Now press the enter key repeatedly until the display is showing unit and the current weighing unit setting. Press the enter key if the setting is correct. Otherwise, press the up or down arrow keys to toggle the weighing unit between lb or kg and press the enter key. Now press the enter key repeatedly until the display is showing CAL for calibrate scale with the current setting: no. Press the up arrow key to select yes to calibrate the scale and press the enter key. Make sure in the scale platform is empty, with the display showing load for load calibration weight, place your test weight on the scale platform, and press the enter key. You should use a minimum of 50% of the scale's capacity however 70-100% is recommended. Refer to the capacity label on the display. The display will change to show the current setting. If the setting is the same as the amount of your test plate, press the enter key. Otherwise, using the arrow keys you will need to change the setting to the amount of your test weight. Press the up or down arrow keys to scroll through the numbers. Verify that the numbers selected are the same as your test weight and press the enter key. Starting at the left and proceeding right, a series of dashes will appear on the display. The dashes will stay on momentarily and then disappear. With the display showing unload, or unload calibration weight, remove your test weight from the scale platform and press the enter key. Starting at the left and proceeding right, a series of dashes will appear on the display. The dashes will stay on momentarily and then disappear. Once the dashes have disappeared and the display is showing the next prompt, press the on off key to turn the scale off, and then press the key again to turn the scale back on. Calibration is complete. Your Apex digital clinical scale is now ready for accurate weighing.

Copy and paste the embed code above.

Watch this video to learn how to calibrate your Apex digital scale.

Cardinal Detecto APEX Specs
Width 17 Inches
Depth 19 1/2 Inches
Height 53 5/16 Inches
Platform Width 17 Inches
Platform Depth 17 Inches
Capacity 300 kg.

600 lb.
Color Silver
Display Type Digital
Function Type BMI

Height

Weight
Power Type Batteries
Type Physicians Scales

Cardinal Detecto APEX Details

Equip your hospital, doctor's office, or clinic with advanced technology by swapping out your old scale for the Cardinal Detecto APEX 600 lb. eye-level digital clinical scale with mechanical height rod. This intuitive physician scale is built to measure both weight and height, featuring a large 17" x 17" platform for patients to stand on and a height rod that measures 24" - 87 1/2" in 1/8" increments. It also comes with dual wheels on the back of the scale base for mobility.

While the height rod offers simple mechanical convenience, the scale itself displays height and weight simultaneously on its intuitive 3/4" high LCD indicator. The weight automatically locks on screen temporarily to ensure easy recording. Easy to read and easy to use, the indicator includes 6 simple push buttons. These range from the basic power function to a Body Mass Index calculator and a Mother/Baby feature that accounts for the weight of a child when held by an adult. The screen also displays the battery level, so staff can monitor when the 12 AA batteries (sold separately) need swapped out. To replace the batteries, simply lift up on the platform cover. The cover lifts off completely for this reason and for easy cleaning.

Measurement Readout:
600 lb. x 0.2 lb.
300 kg x 0.1 kg

Platform Dimensions:
Width: 17"
Depth: 17"
Height: 2 3/4"

Overall Dimensions:
Width: 17"
Depth: 19 1/2"
Height: 53 5/16"
Height Rod: 24" - 87 1/2"

Because this item is not stocked in our warehouse, processing, transit times and stock availability will vary. If you need your items by a certain date, please contact us prior to placing your order. Expedited shipping availability may vary. We cannot guarantee that this item can be cancelled off of the order or returned once it is placed.

  • Made in America

    Made in America

    This item was made in the United States of America.
