Product Overview

  • Uses environmentally friendly R-513A, a non-flammable low Global Warming Potential (GWP) refrigerant
  • Accommodates (2) standard 12” x 20” pans with adapter bars
  • Durable stainless steel construction that's easy to clean
  • Insulated for temperature retention
  • 1/5 hp compressor; 120V
UPC Code:671080897462

Vollrath FC-4CS-02120-R Specs

Quantity
1/Each
Shipping Weight
173 lb.
Width
45 7/8 Inches
Depth
18 Inches
Height
22 1/2 Inches
Cutout Width
44 11/16 Inches
Interior Width
40 3/4 Inches
Cutout Depth
17 5/16 Inches
Interior Depth
11 7/8 Inches
Amps
3.5 Amps
Hertz
60 Hz
Phase
1 Phase
Voltage
120 Volts
Compressor Location
Bottom Mounted
Features
Made in America  NSF Listed
Horsepower
1/5 HP
Installation Type
Drop In
Material
Stainless Steel
Number of Wells
2 Wells
Pan Mounting
Flush
Plug Type
NEMA 5-15P
Power Type
Electric
Refrigeration Type
Cold Wall
Style
Top Mount
Temperature Settings
Fixed
Type
Refrigerated Food Wells

Vollrath FC-4CS-02120-R Details

Keep your most popular cold foods chilled throughout the day with the Vollrath FC-4CS-02120-R standard short side two pan drop-in refrigerated cold food well! Designed to hold pre-chilled food at a safe serving temperature for up to 4 hours, this cold food well is perfect for restaurants, cafeterias, and buffets. The well accommodates 2 standard 12" x 20" pans with adapter bars.

This unit uses a R-513A refrigerant, a non-flammable, low global warming potential refrigerant, so your well is safer and more eco-conscious. The well is surrounded by refrigeration coils for optimal cooling and high density polyurethane foam insulation to help you save energy. A 1/5 hp compressor ensures your food is reliably kept cold throughout the day!

For long-lasting durability, this unit features a 20 gauge galvanized steel exterior housing and 300 series stainless steel well and flange. Plus, there's a full-perimeter drip edge to help contain spills and condensation within the countertop area of the drop-in unit. The remote On / Off switch has a 4' cord for added convenience. A 1" drain siphons runoff from inside the well. Intended for top-mount installation, a 120V electrical connection is required for operation.

Overall Dimensions:
Width: 45 7/8"
Depth: 18"
Height: 22 1/2"

Interior Dimensions:
Width: 40 3/4"
Depth: 11 7/8"

Cutout Dimensions:
Width: 44 11/16"
Depth: 17 5/16

This Item Ships via Common Carrier. For more information and tips to help your delivery go smoothly, click here.

Because this item is not stocked in our warehouse, processing, transit times and stock availability will vary. If you need your items by a certain date, please contact us prior to placing your order. Expedited shipping availability may vary. We cannot guarantee that this item can be cancelled off of the order or returned once it is placed.

Attention CA Residents:

Customer questions about this product

I haven’t heard of R-290, R-600a, R-513a, or R-448A refrigerant before. What is it?

R-290 (also known as high purity propane or CARE 40) and R-600a (also known as refrigerant grade Isobutane or CARE 10) are hydrocarbon refrigerants. R513a (also known as Opteon XP10) and R-448A (also known as Solstice N40) are HFO (hydrofluoroolefin) refrigerants. They are being used by some manufacturers in response to the EPA’s Significant New Alternatives Policy (SNAP) Program.
Ask your own question!
  • NSF Listed

    NSF Listed

    This item has been certified by NSF International to meet applicable product standards on public safety, health, and / or the environment.

  • Made in America

    Made in America

    This item was made in the United States of America.

  • 5-15P

    5-15P

    This unit comes with a NEMA 5-15P plug.

  • UL Listed, Canada

    UL Listed, Canada

    This product has been certified by the Underwriters Laboratories (UL) to meet applicable safety standards required for use in Canada.
