Name: Eversteel by T&S S-0133-A14-B Deck Mount Mixing Faucet with 14" Swing Nozzle and Pre-Rinse Unit with 1.15 GPM Spray Valve
Brand: Eversteel by T&S
SKU: 510S013A14B
Availability: LimitedAvailability

510s013a14bS-0133-A14-B

A deck mount Eversteel pre-rinse faucet with a 14" swing nozzle and a hose.

0:00 / 0:00

Only

$582.45/Each

Ships free with

Add to Wish List

Usually Ships in 2-3 Weeks from manufacturer

Lead times vary based on manufacturer stock

Product Overview

Durable stainless steel construction
14" swing nozzle offers generous clearance
Produces ample output with a 1.15 GPM spray valve
Convenient deck mount configuration
Color-coded lever handles for simplified temperature identification

UPC Code:671262917926

View all Eversteel by T&S Pre-Rinse Faucets

Quantity: 1/Each
Shipping Weight: 14 lb.
Hose Length: 44 Inches
Faucet Width: 12 5/8 Inches
Faucet Height: 37 9/16 Inches
Add-On Faucet: 14 Inches
Add-on Flow Rate: 9.73 GPM
Add-On Type: Swing
Cartridge Type: Compression
Faucet Centers: 8 Inches
Features: NSF Listed With Riser
Finish: Brushed
Handle Type: Lever
Material: Stainless Steel
Mounting Style: Wall Mounted
Mounting Type: Adjustable
Pre Rinse Unit Type: Hose and Spring
Pressure Rating: 20 - 125 PSI
Spray Valve Flow Rate: 1.15 GPM
Temperature Rating: 40 - 140 Degrees F
Type: Pre-Rinse Units
Water Inlet Size: 3/8 Inches

Eversteel by T&S S-0133-A14-B Details

This Eversteel by stainless steel single hole base deck mount mixing faucet is an excellent choice for any establishment looking to upgrade its cleaning process! Featuring 19 11/16" flexible supply hoses with G1/2" female swivel connections compatible with 1/2" NPSM threads, this attractive brushed-finish stainless steel unit is built for exceptional performance in busy establishments. The 14" swing nozzle, which includes a stream regulator outlet, offers optimal clearance in large sinks for easy completion of hand and dishwashing procedures. Stainless steel lever handles with color-coded indexes offer clear visibility for temperature identification at a glance, and quarter-turn Eterna compression cartridges with spring checks work to prevent crossflow.

The pre-rinse unit is constructed with a 44" flexible stainless steel hose and comes complete with a heat-resistant blue handle and hold-down ring to protect your hands during use. The 1.15 GPM spray valve offers the intense power that you need to maintain increased cleanliness in your business. The stainless steel 24" rigid riser and 6" adjustable wall bracket ensure convenient installation and outstanding durability.

Overall Dimensions:
Faucet Height: 37 9/16"
Faucet Width: 12 5/8"
Add-On Faucet: 14"

Because this item is not stocked in our warehouse, processing, transit times and stock availability will vary. If you need your items by a certain date, please contact us prior to placing your order. Expedited shipping availability may vary. We cannot guarantee that this item can be cancelled off of the order or returned once it is placed.

Attention CA Residents:

NSF Listed
This item has been certified by NSF International to meet applicable product standards on public safety, health, and / or the environment.
CSA, US and Canada
This product has been certified by the Canadian Standards Association (CSA) to meet select standards for electrical, plumbing, and/or mechanical products in the United States and Canada.
3/8" Water Connection
This unit comes with a 3/8" water connection for water supply.

Questions & Answers

Looking For Specific Info? Get quick answers to product questions with our AI-powered search.

Frequently Asked Questions From Customers

Can I get a spray valve with a higher flow rate (GPM)?

The maximum flow rate for all commercial pre-rinse spray valves produced after January 28, 2019 is 1.28 GPM – more specific regulations may apply based on the valve’s spray force in ounce-force (ozf).

Product Class 1 (5 ozf or less) – Max Flow Rate: 1 GPM
Product Class 2 (5.01 - 8 ozf) – Max Flow Rate: 1.2 GPM
Product Class 3 (over 8 ozf) – Max Flow Rate: 1.28 GPM

These regulations do not impact spray valves made before January 28, 2019, and are implemented by the US Department of Energy in an effort to improve energy conservation.

Can I use this product to serve drinking water?

This product is not intended for use in applications where potable (drinking) water is dispensed for human consumption.

Does this item have any additional agency approvals and certifications?

There are a wide range of regulations that govern plumbing code! We attempt to list any current certification marks with an official logo on the product page for your convenience. However, additional approvals, codes, and standards this product adheres to may be listed on the product specsheet.

How do I use a wall bracket to stabilize a pre-rinse faucet?

Pre-rinse faucets with a riser may include a wall bracket to help use the wall for added stability. Pre-rinse faucets without a riser will generally not include or need a wall bracket.

If your unit comes with a bracket, or you plan on adding one, the bracket can be installed at whatever height you prefer, but to be effective it should be placed far enough above the base so as to inhibit movement to the riser – placing too close to the base may make it ineffective.

If you intend to use a wall bracket, consider potential concerns with the installation location, such as shelving or windows behind the faucet, that might limit where you can place the bracket.

How is the pre-rinse hose length measured?

Unless otherwise specified, the quoted hose length includes any grips or connectors at the end of the hose, so the actual working length of the hose may be slightly less than described. Please refer to the product's specsheet for more detailed dimensions.

What measurements do I need to install a faucet?

When installing a faucet, these are some of the most common measurements you’ll need:

Faucet Centers: If your faucet has a base with 2 inlets, measure the distance from the center of one inlet to the center of the other. This number must match the spacing of your building’s water lines (adjustable centers will help with the spacing). If mounting through the backsplash on a sink, the center measurement must also fit within the pre-drilled mounting holes.

Flex Hoses: If your faucet has flex hoses make sure that they will reach your building’s water lines.

Spout length: Make sure that the faucet spout will fit comfortably over your sink bowl and not extend too far / not far enough. If you plan to use a swing spout over a multi-bowl sink, make sure it will reach all of the bowls.
