Capacity: 5 Pan
Product Overview
- Independently operated, easy-to-adjust wells for hot or cold service
- 5 pan capacity
- Included stainless steel immersion heater
- Adjustable pan support
- Uses R290 refrigerant; 1/5 hp compressor, 120-240V
- Quantity
- 1/Each
- Shipping Weight
- 660 lb.
- Width
- 78 Inches
- Depth
- 26 Inches
- Height
- 26 Inches
- Cutout Width
- 77 Inches
- Louver Cutout Width
- 20 Inches
- Cutout Depth
- 25 Inches
- Louver Cutout Depth
- 23 1/2 Inches
- Amps
- 6.9 - 10 Amps
- Hertz
- 60 Hz
- Voltage
- 120 - 240 Volts
- Wattage
- 2,500 Watts
- Compressor Location
- Bottom Mounted
- Control Type
- Thermostatic Toggle
- Features
- Made in America NSF Listed With Drain
- Horsepower
- 1/5 HP
- Installation Type
- Drop In
- Insulated
- With Insulation
- Material
- Steel
- Number of Wells
- 5 Wells
- Pan Mounting
- Flush Recessed
- Plug Type
- Hardwire
- Power Type
- Electric
- Refrigerant Type
- R-290
- Size
- Full Size
- Style
- Drop-In
- Temperature Settings
- Adjustable
- Type
- Dual Temperature Wells Refrigerated Food Wells
Delfield N8678-FWP Details
Keep your food hot or cold throughout the day with this Delfield N8678-FWP FlexiWell 78" combination hot / cold 5 pan drop-in food well! With independently operated wells that can be adjusted to serve hot or cold food, this unit offers the versatility your establishment needs for successful food service. The wells feature a stainless steel immersion heater for wet-only heating operation. Plus, this unit features adjustable pan support with flush mounting for hot operation or 2" recessed cooling for cold operation.
A remote control panel features a 3-way Hot / Cold / Off power switch for easy operation, and a thermostat to help monitor temperatures. For your safety, the immersion heater has a high limit safety switch to automatically shut off the heater and illuminate the control panel pilot light. This unit accommodates (5) 6" deep 12" x 20" pans to ensure all your food storage needs are met and includes adapter bars to adjust the unit accordingly. With a galvanized steel exterior and stainless steel top, 1'' drain with screen, and louver included, this unit is durable and comes with everything you need for easy operation. High-density, foamed-in-place polyurethane insulation helps lower energy costs while environmentally friendly R290 refrigerant keeps your unit cold when cooling is needed. A push-in flange gasket is included for added security on the unit's pipes. This unit requires a 120V cold connection, and 208 - 240V hot connection.
Overall Dimensions:
Width: 78"
Depth: 26"
Height: 26"
Cutout Dimensions:
Width: 77"
Depth: 25"
Louver Cutout Dimensions:
Width: 20"
Depth: 23 1/2"
This Item Ships via Common Carrier. For more information and tips to help your delivery go smoothly, click here.
Because this item is not stocked in our warehouse, processing, transit times and stock availability will vary. If you need your items by a certain date, please contact us prior to placing your order. Expedited shipping availability may vary. We cannot guarantee that this item can be cancelled off of the order or returned once it is placed.
Customer questions about this product
Does free shipping apply to this Delfield item if I am shipping it to a residential address?
I haven’t heard of R-290, R-600a, R-513a, or R-448A refrigerant before. What is it?
Hardwired
This product must be hardwired by a professional; it does not plug into a standard wall outlet.
NSF Listed
This item has been certified by NSF International to meet applicable product standards on public safety, health, and / or the environment.
Made in America
This item was made in the United States of America.
UL Listed, US & Canada
This product has been certified by the Underwriters Laboratories (UL) to meet applicable safety standards required for use in the United States and Canada.
CSA Sanitation NSF4
This item is certified for the U.S. market to the requirements of the NSF/ANSI 4 standard of the Canadian Standards Association (CSA).
CSA Sanitation NSF7
This item is certified for the U.S. market to the requirements of the NSF/ANSI 7 standard of the Canadian Standards Association (CSA).
