Traulsen: How to Install #4 Trayslides on G Series 2-Section Video

#4 Trayslides: How to Install on G-Series 2-Section. Step 1: Label the top side of each Pilaster. The top should have the smaller gap from end to first cut out. Step 2: Remove the Loadsure Guard (duct). Using a flat head screwdriver, pop out the plugs to reveal the screw holes. Step 3: Install the outside panel pilasters (Part # 342-6026-00) with 6 thumb screws each. Step 4: Install the other Pilasters in the same fashion. Back left Pilaster (Part # 340-60034-00). Front left Pilaster (Part # 342-60032-00). Step 5: Begin installing the Trayslides from bottom to top. (Part # 701-040842-00). Step 6: Test the fit to make sure that the Pilasters and Trayslides have been installed level.
