Luxor: Innovation Workspace Product Solutions. Assembly instructions for the 48" and 60" wide electric stand up desk.
Step 1a: With a mallet, attach the frame caps (R) to frame (A & B).
Step 1b: Attach locking casters (J) with wrench (9) to the long end of the frame (B).
Step 1c: Attach non-locking casters (K) with wrench (9) to other end of frame (B).
Step 1d: Repeat the same process. Attach locking casters (J) with wrench (9) to frame (A).
Step 1e: Repeat. Attach non-locking casters (k) with wrench (9) to frame (A).
Step 2a: With assistance, flip the unit's left and right frame (A & B) so casters are facing up.
Step 2b: Make sure the indented center holes in cross bars (C) are facing toward the casters.
Step 2c: With screws (4 x 4) and Allen wrench (2), attach cross bars (C x 2) to frame (A &B).
Make sure not to fully tighten screws (8) until all are in place.
Step 3a: Attach the electric adjustment housing (D) to frame so that the screw holes line up properly.
Step 3b: Attach screws (8 x 16) with Allen wrench (1) to housing (D) making sure not to fully tighten any of the screws. Minor adjustments may be needed so that screw holes line up properly.
Step 4a: with assistance flip the desk upright.
Step 4b: Push the locking casters into the lock position to prevent movement during assembly.
Step 4c: OPTIONAL: Install any electric attachments (sold separately) before attaching desk to frame.
Step 5a: Insert attachment socket (N) onto rotating hex cross bar (E) so that hex side is facing towards center of cross bar.
Step 5b: Insert hex end of cross bar (E) into hex opening of motor. Make sure socket (N) was inserted onto opposite side.
Step 5c: Place cross bar (E) and push the socket (N) so that it firmly locks into the metal extrusion.
Step 6a: Mount power supply (H) onto the metal plate on the frame.
Step 6b: Loop electric controller (G) underneath the electric housing.
Step 7: Attach cable that is connected to controller to right plug. Attach cable connected to motor to center plug. Plug in electric to test system BEFORE attaching the desktop.Hold the right button until the desk is at its lowest position and wait for 5 seconds.
This step needs to be performed anytime the unit has been unplugged or in the event of a power outage. After a reset has been performed the desk will lower and raise at the proper speeds.
Step 8a: Make sure two screw holes are facing towards the front of the desk. This is where you will mount push button controls (G).
Step 8b: With assistance place desktop (F) on the top of frame.
Step 8c: Attach screw (5 x 4) in the desktop (F) using Allen wrench (2).
Step 9: Attach remaining screws (3 x 2) into desktop (F) using Allen wrench (2).
Step 10a: Place push button controller (G) onto plate (P).
Step 10b: Push screws (6 x 2) into controller (G) and through plate (P).
Step 10c: Place push button controller assembly onto pre-drilled screw holes towards right edge of desktop (F).
Step 10d: With Phillips screwdriver tighten screws (6 x 2) to desktop (F).
Step 10e: Remove protective strip on the adhesive pad.
Step 10f: Place clips (L) in desired position, making sure to leave plenty of slack for cables during desk adjustments as well as making sure to keep clear of any moving parts or surfaces.
