$17,905.00/Each
This product is no longer available. We've left this page up for reference only.
Usually Ships in 4-5 Weeks from manufacturer
Lead times vary based on manufacturer stock
Product Overview
- Black exterior and interior with mirrored end panels
- Open design increases impulse sales; shallow depth is great for convenience stores
- Top mounted compressor uses R-404A refrigerant
- Maintains temperatures of 40 degrees Fahrenheit in ambient temperatures up to 80 degrees Fahrenheit
- Environmentally friendly EnergyWise design reduces energy consumption by more than 50%
- Removable deck pan for easy servicing of the evaporator coil and refrigeration connections
- 4 removable metal shelves can be adjusted on 1" centers
- 208/240V
- Quantity
- 1/Each
- Shipping Weight
- 1200 lb.
- Width
- 92 1/8 Inches
- Depth
- 25 Inches
- Height
- 81 7/8 Inches
- Amps
- 16 Amps
- Hertz
- 60 Hz
- Phase
- 1 Phase
- Voltage
- 208 - 240 Volts
- Wattage
- 3,203 Watts
- Color
- Black
- Compressor Location
- Top Mounted
- Display Case Type
- Refrigerated
- Features
- Made in America
- Front Style
- Open-Air
- Installation Type
- Freestanding
- Number of Shelves
- 4 Shelves
- Plug Type
- NEMA 6-20P
- Refrigerant Type
- R-404A
- Sections
- 1 Section
- Service Type
- Self Service
- Style
- Vertical
- Temperature Range
- 40 Degrees F
Structural Concepts B824TM ALL BLACK Details
The Structural Concepts B824TM Oasis black 92 1/8" air curtain merchandiser is a great grab-and-go solution for your deli, bakery, coffee shop, or market! Thanks to its shallow 25" depth, this unit is an excellent choice even for convenience stores and other operations working with narrow aisles and otherwise limited space. This refrigerated air curtain merchandiser maintains product temperatures of 40 degrees Fahrenheit while providing easy access to increase impulse sales. Compared to competitive models, the environmentally-friendly EnergyWise design will reduce your energy consumption by a staggering 50% or higher, which significantly lowers operating costs.
Featuring an exclusive "Breeze-E" design with flexible synthetic hosing, the refrigeration system easily slides out of the unit for quick and efficient servicing. This intelligent system has a microprocessor-controlled sensor that senses and adjusts to ambient temperature conditions. This results in more consistent product temperatures and longer product shelf life! The top mounted compressor runs on R-404A refrigerant and requires less maintenance than bottom mounted alternatives since it's less susceptible to clogs from dust and other debris. Plus with removable deck pans, you'll have full access to the evaporator coils and refrigeration connections.
Each of the 4 metal shelves are removable and can be adjusted on 1" centers, providing you with the ability to customize the interior of your unit to best suit the products you are displaying. An attractive black interior and exterior, along with full end panels with a mirrored interior help attractively showcase your products. The T-8 top light will illuminate your products as well, which helps to create an eye-catching display. This energy-efficient air curtain merchandiser requires a 208/240V electrical connection.
Overall Dimensions:
Width: 92 1/8"
Depth: 25"
Height: 81 7/8"
Attention CA Residents:Customer questions about this product
Can I put warm items in my air curtain merchandiser to chill them?
Can this item fit through a standard height 80" doorway ?
Made in America
This item was made in the United States of America.
ARI / AHRI
This certification is awarded by the Air-Conditioning, Heating, and Refrigeration Institute to denote products of exceptional performance.
ETL, US & Canada
This product has been certified by ETL, a division of the Intertek Group, to meet applicable electrical product safety standards required for use in the United States and Canada.
ETL Sanitation
This product has been certified by ETL, a division of the Intertek Group, to meet applicable sanitation standards required for use in the United States and Canada.
6-20P
This unit comes with a NEMA 6-20P plug.
Resources and Downloads for
Structural Concepts B824TM ALL BLACK
A PDF viewer is required to view this product's information. Download Adobe Acrobat software
Warranty Info
RESIDENTIAL USERS: Vendor assumes no liability for parts or labor coverage for component failure or other damages resulting from installation in non-commercial or residential applications. Your warranty will be voided if installed in non-commercial or residential applications.
