Product Overview
- Open design increases impulse sales
- Self-contained, slide out refrigeration system with microprocessor-controlled temperature sensor
- Bottom mount compressor; maintains temperatures of 40 degrees Fahrenheit or less
- Environmentally friendly EnergyWise design reduces energy consumption by more than 50%
- Removable deck pan for easy servicing of the evaporator coil and refrigeration connections
- 4 adjustable metal shelves and T-8 toplight to illuminate products
Other Products from this Line
- Quantity
- 1/Each
- Shipping Weight
- 1150 lb.
- Width
- 47 5/8 Inches
- Depth
- 32 1/4 Inches
- Height
- 82 1/4 Inches
- Amps
- 10.16 Amps
- Hertz
- 60 Hertz
- Phase
- 1 Phase
- Voltage
- 208 - 240 Volts
- Wattage
- 1,908 Watts
- Compressor Location
- Bottom Mounted
- Display Case Type
- Refrigerated
- Features
- Made in America
- Front Style
- Open-Air
- Installation Type
- Freestanding
- Number of Shelves
- 4 Shelves
- Plug Type
- NEMA 6-20P
- Refrigerant Type
- R-404A
- Sections
- 1 Section
- Service Type
- Self Service
- Style
- Vertical
- Temperature Range
- 40 Degrees F
Customer questions about this product
Can I put warm items in my air curtain merchandiser to chill them?
What does the -QS or -E3 mean at the end of the manufacturer's item number?
Can this item fit through a standard height 80" doorway ?
Structural Concepts B4732 Details
The Structural Concepts B4732-QS Oasis 47" air curtain merchandiser is a great grab-and-go solution for your deli, bakery, convenience store, coffee shop, or market! This refrigerated air curtain merchandiser maintains product temperatures of 40 degrees Fahrenheit while providing easy access to increase impulse sales. Compared to competitor units, the environmentally-friendly EnergyWise design will reduce your energy consumption by a staggering 50% or higher, which significantly lowers operating costs.
Featuring an exclusive "Breeze-E" design with flexible synthetic hosing, the refrigeration system easily slides out of the unit for quick and efficient servicing. This intelligent system has a microprocessor-controlled sensor that senses and adjusts to ambient temperature conditions. This results in more consistent product temperatures and longer product shelf life! The bottom mounted compressor ensures easy maintenance and increases efficiency because it draws air from the coolest area of your establishment. Plus with removable deck pans, you'll have full access to the evaporator coils and refrigeration connections.
Each of the 4 metal shelves are removable and can be adjusted on 1" centers, providing you with the ability to customize the interior of your unit to best suit the products you are displaying. An attractive black interior, along with customizable exterior panels with a mirrored interior help attractively showcase your products. The T-8 top light will illuminate your products as well, which helps to create an eye-catching display. This energy-efficient air curtain merchandiser requires a 208-240V electrical connection.
Overall Dimensions:
Width: 47 5/8"
Depth: 32 1/4"
Height: 82 1/4"
This Item Ships via Common Carrier. For more information and tips to help your delivery go smoothly, click here.
Because this item is not stocked in our warehouse, processing, transit times and stock availability will vary. If you need your items by a certain date, please contact us prior to placing your order. Expedited shipping availability may vary. We cannot guarantee that this item can be cancelled off of the order or returned once it is placed.
Made in America
This item was made in the United States of America.
ARI / AHRI
This certification is awarded by the Air-Conditioning, Heating, and Refrigeration Institute to denote products of exceptional performance.
ETL, US & Canada
This product has been certified by ETL, a division of the Intertek Group, to meet applicable electrical product safety standards required for use in the United States and Canada.
ETL Sanitation
This product has been certified by ETL, a division of the Intertek Group, to meet applicable sanitation standards required for use in the United States and Canada.
6-20P
This unit comes with a NEMA 6-20P plug.
