$3,749.00/Each

Ships free with Plus

Earn up to $112.47 back (11,247 points)with a Webstaurant Rewards Visa® Credit Card

Size: 60"

Usually Ships in 3 Business Days from manufacturer

Lead times vary based on manufacturer stock

Product Overview

  • Ideal for commercial entranceways up to 10'
  • Creates a barrier between 2 environments; reduces heat loss
  • Remote controls and built-in keypad
  • Mounts on walls and ceiling
  • Energy-efficient motor starts quickly
UPC Code:841530046683

Schwank Ltd AC-KE60-60 Specs

Quantity
1/Each
Shipping Weight
61.7 lb.
Width
61 7/16 Inches
Depth
13 5/8 Inches
Height
8 5/16 Inches
Amps
7.7 - 8.6 Amps
Hertz
60 Hz
Phase
3 Phase
Voltage
600 Volts
Wattage
4,000 - 5,000 Watts
Airflow Rating
1,592 CFM
Color
Black
Features
Electric Heater  Made in America
Installation Type
Surface Mounted
Material
Powder Coated Metal  Zinc-Plated Steel
Noise Level
72 dB
Plug Type
Hardwire
Speeds
3 Speed
Style
Back Door  Front Door
Type
Air Curtains

Schwank Ltd AC-KE60-60 Details

Protect the temperature inside your establishment with this Schwank Select10 ambient air curtain! This energy-efficient air curtain features a sleek black color and is ideal for small openings like entranceways where a long, narrow airflow is required. It creates a temperature-separating air barrier to prevent cold air from pushing in and hot air from going out, reducing heat loss through the opening.

This air curtain features remote controls with variable speed control and a built-in keypad. It has a compact design that can be easily positioned. It's simple to angle on the bracket, which can be used for both wall and ceiling mounting up to 10', and it boasts low sound levels. The air curtain features a durable, accessible housing that snaps on and latches for easy access for maintenance. It also features a modern design and sleek shape that will blend seamlessly into your space and stand up to hard use even in the most demanding applications. It requires a 600V electrical connection for operation.

Overall Dimensions:
Width: 61 7/16"
Depth: 13 5/8"
Height: 8 5/16"

Because this item is not stocked in our warehouse, processing, transit times and stock availability will vary. If you need your items by a certain date, please contact us prior to placing your order. Expedited shipping availability may vary. We cannot guarantee that this item can be cancelled off of the order or returned once it is placed.

Attention CA Residents:

Customer questions about this product

Why are the dimensions in the title different from the actual dimensions in the description?

The dimensions given in the title represent an “industry standard” – a basic size that most manufacturers produce and that people in the industry use to easily identify a type of item. However, not all manufacturers produce their products the same way. For example, a title might say 12", but the item may actually be slightly larger or smaller. We include both measurements to help you find the product you’re looking for, and so you also know how large the product actually is.
Ask your own question!
  • Made in America

    Made in America

    This item was made in the United States of America.

  • Hardwired

    Hardwired

    This product must be hardwired by a professional; it does not plug into a standard wall outlet.
