Type: 9,000 BTU
Product Overview
- Provides 2-in-1 cooling and heating
- Features 6-zone climate control in 1 unit, conditioning multiple areas
- Operates quietly to avoid background noise
- Includes a wireless remote control with digital screen for convenience
- Ideal for areas that are 160-325 sq. ft.; 208-230V, 9,000 BTU
- Quantity
- 1/Each
- Shipping Weight
- 133 lb.
- Indoor Unit Width
- 27 1/2 Inches
- Outdoor Unit Width
- 30 1/8 Inches
- Indoor Unit Depth
- 20 Inches
- Outdoor Unit Depth
- 11 7/8 Inches
- Indoor Unit Height
- 7 7/8 Inches
- Outdoor Unit Height
- 21 7/8 Inches
- Hertz
- 60 Hz
- Phase
- 1 Phase
- Voltage
- 208 - 230 Volts
- Color
- White
- HSPF
- 11.5 Rating
- Mounting Style
- Freestanding
- Plug Type
- Hardwire
- Range
- 160 - 325 Square Feet
- Refrigerant Type
- R-410A
- SEER
- 21 Rating
- Speeds
- Variable
- Temperature Range
- 62 - 86 Degrees F
- Total BTU
- 9,000 BTU
- Type
- Air Conditioners DIY Heat Pump Systems
Parker Davis HVAC International RYB009GMFILDAD-16 Details
This Pioneer Series RYB-D22 RYB009GMFILDAD-16 mini split ducted concealed AC / heat pump system provides cooling and heating all in one! With its 6-way capacity, this unit can condition 6 separate areas of your business from one location, accommodating different temperatures. Its variable speed motor is virtually inaudible, making it distraction-free. Plus, the digital wireless remote controller that comes standard with your unit enables you to have full control of the settings from an easily accessible area.
For a discreet look, this slim unit conceals nicely in the ductwork of your business, and it's suitable for a space that's 160-325 sq. ft. It includes a preset timer that will turn the fan on and off, and in the event of a power outage, will automatically save its current settings to ensure everything gets back on track when the power returns.
This mini split system has a 21 SEER energy rating and uses R410A refrigerant, using less energy than the average air conditioner and making it an environmentally-friendly choice for your business. It intuitively detects refrigerant leakage and shuts off immediately if leaking, saving the compressor from damage. To ensure the comfortability of guests year-round, the indoor fan speed is regulated from the lowest grade to the set grade according to the evaporator's temperature, which counters any cold air coming in while in heating mode. A 208-230V, hardwired, electrical connection is required for operation and should be installed by a professional.
Indoor Unit Dimensions:
Width: 27 1/2"
Depth: 20"
Height: 7 7/8"
Outdoor Unit Dimensions:
Width: 30 1/8"
Depth: 11 7/8"
Height: 21 7/8"
This Item Ships via Common Carrier. For more information and tips to help your delivery go smoothly, click here.
Because this item is not stocked in our warehouse, processing, transit times and stock availability will vary. If you need your items by a certain date, please contact us prior to placing your order. Expedited shipping availability may vary. We cannot guarantee that this item can be cancelled off of the order or returned once it is placed.
Customer questions about this product
What is the SEER rating on my item?
ARI / AHRI
This certification is awarded by the Air-Conditioning, Heating, and Refrigeration Institute to denote products of exceptional performance.
Hardwired
This product must be hardwired by a professional; it does not plug into a standard wall outlet.
Need Parts & Accessories?
Show replacement parts and accessories for Parker Davis HVAC International RYB009GMFILDAD-16 today!
Resources and Downloads for
Parker Davis HVAC International RYB009GMFILDAD-16
A PDF viewer is required to view this product's information. Download Adobe Acrobat software
Warranty Info
Warranty is 5 years on parts and the compressor, upon registration of the system by paper or website within 90 days of install. Labor costs are not covered.
