Pioneer Diamante Essenza WYT-17 WYT024GLUI17RL High Wall-Mounted Ductless Mini Split AC / Heat Pump System - 17 SEER2, 23,000/22,400 BTU, 208-230V

Pioneer WYT024GLUI17RL Details

This Pioneer Diamante Essenza WYT-17 ductless mini split AC / heat pump system provides all-in-one cooling, heating, dehumidification, and ventilation for your establishment. With 23,000 BTU of cooling power and 22,400 BTU of heating power, this system is recommended for heating / cooling spaces ranging from 600 to 950 sq. ft. The included air handler wall mounts indoors at a minimum of 6' high while the heat pump mounts outdoors. This system has a 17 SEER2 energy rating and uses R-32 refrigerant to conserve energy.

This system is easy to operate with a digital wireless remote controller with an LCD screen. This remote allows you to adjust the temperature, select eco and sleep modes to conserve energy, and set the timer. It can also set a self-cleaning cycle, save your favorite settings as memories, or use the iFeel mode to detect and adjust to the local temperature. You can also select low, medium, high, and mute modes or a turbo mode specifically designed for high-demand applications.

The included air handler operates using a quiet motor with ball bearings for non-disruptive use. Its automatic synchronized air discharge louvers ensure proper air circulation. It features a digital backlit LED display to show the set temperature, and it is constructed with a durable ABS plastic casing. It offers auto changeover, dry, and fan only modes. It comes with washable, removable air filter cartridges to capture dust, pollen, and other airborne particles from the indoor air.

The included heat pump has a variable-speed DC inverter and a high-output, variable-speed compressor for efficient use. It comes pre-charged with R-32 refrigerant, and it operates using a permanently lubricated EC-DC outdoor motor. It features a heavy coat of baked enamel paint and is made with anti-discoloration formulated plastic dyes to prevent yellowing, fading, and discoloration. Plus, it has intelligent defrosting to manage when and how it defrosts in cold weather.

This system includes season sensitive operational logic to automatically adjust its operational parameters depending on whether it is heating or cooling season. It is built for use in ambient temperatures as low as 5 degrees Fahrenheit when heating and as high as 122 degree Fahrenheit when cooling. Its auto-restart memory allows the machine to automatically resume operation with the previous settings after a power outage. This unit includes overload protection for the motors and dual drainage ports. It requires a 208-230V electrical connection for operation.

Kit Includes:
- Air handler
- Heat pump
- Wireless remote
- Remote control wall holder
- Remote batteries
- 16' copper lines
- 16' electrical wire
- 10' drain
- Wall passage sleeve
- Putty for wall hole
- Leak guard sealer
- Wrapping tape

Air Handler Dimensions:
Width: 39 3/4"
Depth: 8 3/4"
Height: 12 3/8"

Heat Pump Dimensions:
Width: 34"
Depth: 13 3/4"
Height: 23 5/8"

This Item Ships via Common Carrier. For more information and tips to help your delivery go smoothly, click here.

Due to US DOT shipping regulations, we are unable to ship this product to Alaska, Hawaii, and international destinations. It is also ineligible for next day or second day shipping and cannot be returned. Please contact Customer Solutions prior to placing your order if you have any questions or concerns.

Because this item is not stocked in our warehouse, processing, transit times and stock availability will vary. If you need your items by a certain date, please contact us prior to placing your order. Expedited shipping availability may vary. We cannot guarantee that this item can be cancelled off of the order or returned once it is placed.
