$376.49/Each

Ships free with Plus

Earn up to $11.29 back (1,129 points)with a Webstaurant Rewards Visa® Credit Card

Usually Ships in 2-3 Weeks from manufacturer

Lead times vary based on manufacturer stock

Product Overview

  • Multi-purpose unit accommodates (1) 50' air, water, or oil hose (sold separately)
  • Features lubricated precision bearings and a cartridge-style spring motor for high performance
  • Constructed with powder-coated steel
  • 90 degree, solid brass NPT swivel inlet allows for swift maintenance and easy hose installation
  • Side mount design is perfect for installation on flat, vertical surfaces
UPC Code:0674255735460

Coxreels SR17WL-150 Specs

Quantity
1/Each
Shipping Weight
26 lb.
Length
17 Inches
Width
7 7/8 Inches
Height
18 1/4 Inches
Base Length
2 1/2 Inches
Base Height
13 Inches
Application
Air  Water
Color
Blue
Faucet Centers
Swivel Inlets
Features
Made in America  Rust-Resistant
Material
Powder Coated Steel
Mounting Style
Side Mounted
Pressure
Low
PSI
200 PSI
Return Style
Motor Driven  Retractable
Style
Open
Type
Reels

Coxreels SR17WL-150 Details

Outfit your business with this Coxreels SW Series spring driven right side mount air and water hose reel for low pressure 1/4" x 50' hose! This hose reel is perfect for industrial businesses where a grease or hydraulic hose is needed but space is limited. The heavy-duty steel mounting base stands up to heavy use in a commercial environment and allows easy access to the hose reel for maintenance. The CPC powder coat finish is chip-resistant and provides long-term durability.

Constructed with a 2-bolt right side mounting pattern, this hose reel can be installed on any vertical surface, such as cabinets, beams, service vehicles, and tool benches. It mounts and detaches easily, making it ideal for both temporary and permanent installation. This reel is designed with versatility in mind, as it contains an enclosed, factory-tuned, cartridge-style spring motor with a stainless steel spring. This makes the motor long-lasting, rust-resistant, and ensures that it is easily accessible and removable when needed. This reel also features a locking mechanism that allows you to secure the hose at your preferred length so you're able to service every area of your workstation without compromising on location. Plus, the included hose control bar provides security by keeping the hose securely on the reel.

This hose reel is compatible with a low pressure 1/4" x 50' Oxy-Acetylene hose (sold separately). It boasts a solid steel axle and lubricated precision bearings that allow you to rotate the reel 360 degrees with ease. Its rolled exterior design and robotically spun and ribbed discs lend strength and security to the unit. This reel is fitted with (1) 90 degree, full-flow, solid brass NPT swivel that allows for swift maintenance and easy hose installation. The hose reel is rated for 200 PSI working pressure.

Overall Dimensions:
Length: 17"
Width: 7 7/8"
Height: 18 1/4"

Mounting Base Dimensions:
Length: 2 1/2"
Height: 13"

Because this item is not stocked in our warehouse, processing, transit times and stock availability will vary. If you need your items by a certain date, please contact us prior to placing your order. Expedited shipping availability may vary. We cannot guarantee that this item can be cancelled off of the order or returned once it is placed.

Attention CA Residents:

Customer questions about this product

Can I use this product to serve drinking water?

This product is not intended for use in applications where potable (drinking) water is dispensed for human consumption.
Ask your own question!
  • Made in America

    Made in America

    This item was made in the United States of America.

Resources and Downloads for
Coxreels SR17WL-150

A PDF viewer is required to view this product's information. Download Adobe Acrobat software

Warranty Info

2 year warranty except any included hoses which are under warranty for 90 days.
