$11,855.00/Each

This product is no longer available. We've left this page up for reference only.

Usually Ships in 4-5 Weeks from manufacturer

Lead times vary based on manufacturer stock

Product Overview

  • Open design increases impulse sales
  • Self-contained, slide out refrigeration system with microprocessor-controlled temperature sensor
  • Bottom mount compressor; maintains temperatures of 40 degrees Fahrenheit or less
  • Environmentally friendly EnergyWise design reduces energy consumption by more than 50%
  • Removable deck pan for easy servicing of the evaporator coil and refrigeration connections
  • 2 adjustable metal shelves and T-8 toplight to illuminate products
  • 208/240V
UPC Code:400011945947
View all Structural Concepts Horizontal & Vertical Air Curtain Merchandisers

Structural Concepts CO65R Specs

Quantity
1/Each
Shipping Weight
1100 lb.
Width
71 1/4 Inches
Depth
32 5/8 Inches
Height
61 5/8 Inches
Interior Width
69 1/4 Inches
Interior Depth
23 Inches
Interior Height
30 1/4 Inches
Amps
10.27 Amps
Hertz
60 Hertz
Phase
1 Phase
Voltage
208 - 240 Volts
Wattage
1,917 Watts
Compressor Location
Bottom Mounted
Display Case Type
Refrigerated
Features
Made in America
Front Style
Open-Air
Installation Type
Freestanding
Number of Shelves
2 Shelves
Plug Type
NEMA 6-20P
Refrigerant Type
R-404A
Service Type
Self Service
Style
Vertical

Customer questions about this product

Can I put warm items in my air curtain merchandiser to chill them?

This unit is intended for maintaining cold product temperatures, but not for making warm items colder. For best results, items loaded into this unit should be pre-chilled to proper serving temperatures, and ambient conditions should not exceed 75 degrees Fahrenheit / 55 percent relative humidity.

What does the -QS or -E3 mean at the end of the manufacturer's item number?

These suffixes relate to the shipping time. QS stands for Quick Ship, which usually ships in 10 business days. E3 stands for Express 3 and usually ships in 3 business days.

Ask your own question!

Structural Concepts CO65R Details

The Structural Concepts CO65R-QS air curtain merchandiser is a great grab-and-go solution for your deli, bakery, convenience store, coffee shop, or market! This refrigerated air curtain merchandiser maintains product temperatures of 40 degrees Fahrenheit while providing easy access to increase impulse sales. As an added benefit, the environmentally-friendly EnergyWise design will reduce your energy consumption by a staggering 50% or higher, which significantly lowers operating costs.

Featuring an exclusive "Breeze-E" design with flexible synthetic hosing, the refrigeration system easily slides out of the unit for quick and efficient servicing. This intelligent system has a microprocessor-controlled sensor that senses and adjusts to ambient temperature conditions. This results in more consistent product temperatures and longer product shelf life! The bottom mounted compressor ensures easy maintenance and increases efficiency because it draws air from the coolest area of your establishment. Plus with removable deck pans, you'll have full access to the evaporator coils and refrigeration connections.

Each of the 2 shelves are removable and can be adjusted on 1" centers, providing you with the ability to customize your unit. An attractive black interior, along with customizable exterior panels with a mirrored interior help attractively showcase your products. The T-8 top lights will illuminate your products as well, which helps to create an eye-catching display. This energy-efficient air curtain merchandiser requires a 208/240V electrical connection.

Overall Dimensions:
Width: 71 1/4"
Depth: 32 5/8"
Height: 61 5/8"

Attention CA Residents:

Attention CA Residents

WARNING:This product can expose you to chemicals including lead, which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, go to www.p65warnings.ca.gov.

  • ETL Sanitation

    ETL Sanitation

    This product has been certified by ETL, a division of the Intertek Group, to meet applicable sanitation standards required for use in the United States and Canada.

  • ETL, US & Canada

    ETL, US & Canada

    This product has been certified by ETL, a division of the Intertek Group, to meet applicable electrical product safety standards required for use in the United States and Canada.

  • 6-20P

    6-20P

    This unit comes with a NEMA 6-20P plug.

  • Made in America

    Made in America

    This item was made in the United States of America.

Resources and Downloads for
Structural Concepts CO65R

A PDF viewer is required to view this product's information. Download Adobe Acrobat software

Warranty Info

RESIDENTIAL USERS: Vendor assumes no liability for parts or labor coverage for component failure or other damages resulting from installation in non-commercial or residential applications. Your warranty will be voided if installed in non-commercial or residential applications.

Resources

  • Refrigerated Merchandisers Buying Guide
