Ice Machine

Buying Guide

Header Image

Nearly every type of food service business needs an ice machine. Because there are so many different configurations and styles available, it's important to understand what is available to find the best ice maker to suit your business' needs.

Configurations

While there are variations within each type, commercial ice machines generally fall into three basic styles.

Manitowoc Indigo Series ID-0322A 335 Pound Full Size Cube Ice Machine 22 inch Wide - Air Cooled

Modular, or Ice Machine Head

Modular ice machines are commonly available in 22", 30" and 48" widths, and are designed to sit on top of an ice machine bin, an ice machine dispenser, or a soda dispenser. Ice outputs range from 250 lbs. per day to well over 1000 lbs. per day.


Manitowoc UD-0190A NEO Undercounter Full Cube Ice Machine Air Cooled - 198 lb.

Undercounter Ice Machines

For small bars, cafes, or businesses that don't need as much ice, an undercounter, or self-contained ice machine may be all that's needed. These small ice makers combine the ice machine with a storage bin, and fit under most 40" high counters. Ice outputs generally top out at about 350 lbs. per day, though a few higher capacity models do exist.


Follett 25CI400W-L Symphony Countertop Water Cooled Ice Maker and Water Dispenser - 25 lb. Storage

Countertop Ice Dispenser / Makers

These compact units are often found in health care settings, and may dispense water too. They have a small bin but can still produce up to 400 lbs. of ice per day, making them a great small commercial ice maker. They also usually dispense nugget style ice, which is easier to chew.

Ice Types

Understanding the different types of ice cubes that commercial ice machines can produce will help you choose the right type for your needs.

Cube Ice

  • Most common; melts slower and can potentially reduce customer ice consumption compared to other types
  • "Full" (approximately 7/8" x 7/8") cubes
  • "Half" (half of full) cubes
  • "Regular" (approximately 1 1/8" x 1 1/8" x 7/8") cubes

Nugget Ice

  • Slow melting; most common in health care industry because it's softer and easier to chew than cube ice
  • Also called compressed nugget, or "chewblet" ice

Flake Ice

  • Small, soft flakes of ice that cool rapidly and mold to any shape
  • Used mainly in ice displays for seafood, meat, fish, and on salad bars; can also be used in blended drinks

Compressor Types

Once you've decided what type of machine and ice you want, the next important consideration to make is whether you want an air-cooled, water-cooled, or remote compressor.

Manitowoc Indigo Series IY-0454A 450 Pound Half Size Cube Ice Machine 30 inch Wide - Air Cooled

Air Cooled

Air cooled ice machines are often the most cost-effective type of ice machine, as they do not involve any additional water costs. Many air cooled models even achieve Energy Star Compliance. Air cooled condensers do need at least 6" of clearance around air intake and discharge areas, but they are a good choice for the majority of users.



Water Cooled

A water cooled ice machine is a better choice than an air cooled model only if one or more of the following conditions exists:

    IMI Cornelius CCM0522WH1 Nordic Water Cooled Ice Cuber 507 Pounds, Half Size Ice Cubes 115V
  • The machine would be installed where ambient air temperatures are greater than 80 degrees Fahrenheit
  • The machine would be installed in an area where the air contains a high level of contaminants, like grease
  • The machine would be installed in an area with poor air circulation or limited space where clearance limitations of an air cooled machine could not be met

Again, unless one or more of the above conditions exist, a water-cooled machine is probably not the best choice, since water consumption will be much higher than with an air cooled ice machine. In fact, some municipalities do not even allow the use of a water cooled ice machine for that reason!



IMI Cornelius RC05001 Remote Ice Machine Condenser- 115V 1 Phase

Remote Cooled

With remote condenser ice machines, the condenser is air cooled, and mounted outdoors, usually on a roof. Refrigerant lines run between the condenser and the machine. As a result, a remote condensing ice machine will be much quieter than its air or water-cooled counterparts.

However, installation and maintenance of a remote setup can be much more costly, and a remote condenser ice machine is usually only chosen if conditions prohibit the use of an air cooled or water cooled unit.

Ice Machine Sizing

Once you've settled on the type of ice machine you need and the type of ice you want, you must select a machine with the right capacity for your needs.

  • For new businesses: Make sure your estimates allow for growth, or you could quickly exceed the production capacity of the machine you wish to purchase.
  • For replacement ice machines: Did your current ice machine keep up with demand? If not, you will need to evaluate how much capacity you were lacking and factor that into your calculations.
  • For everyone: Ice consumption at peak times should be considered, as well as any possibility for a future increase in demand. It's always better to have extra ice on hand than to rely on a machine that is too small to meet your needs.

Benefits of Using Multiple Ice Machines

It may seem easier to supply all your ice from one large machine and bin, but in the end this is usually inefficient. With only one large machine, your staff will constantly be running back and forth from the ice bin to soda machines, under bar ice chests, and salad bars…costing you time and also increasing chances of cross-contamination.

Instead, consider using several smaller machines, one on top of the soda dispenser, a small underbar unit, and a small ice maker with a bin near your salad bar, for example. This way your staff will always have ice when and where they need it, while also keeping the ice safe and sanitary!


Installation Considerations

  • Space and Placement: Make sure you have enough space for the machine, bin, and filter. Adequate air flow is crucial for maximum ice production. Carefully considering the placement of the machine and bin can also increase worker productivity and efficiency.
  • Water Supply & Floor Drain: Your ice machine will need a cold water supply with a shutoff valve. A floor drain is needed too. Check your local codes for specific drain type and placement requirements.
  • Power Supply: Many ice machines do not come with a cord and plug, so a visit from your electrician will be needed to hard wire the machine. Make sure you understand and can meet the machine's power requirements—not all machines operate on standard 110V electric. Electrical requirements and any other special installation considerations will always be found on the machine's Specification Sheet.

Use the chart below to get an idea for how much ice you might use. It's also important to keep in mind that ambient room temperature and ventilation considerations will affect the maximum output of any ice machine. This information is usually available on the manufacturer's Specification Sheet.

Ice Sizing Guide (Includes 20% Safety Factor)

Application Type Typical Daily Ice Use Ice Needed for 100 Customers Ice Needed for 250 Customers Ice Needed for 500 Customers Ice Needed for 1000 Customers Ice Needed for 1500 Customers
Restaurant 1.5 lbs ice per meal sold 180 lbs. 450 lbs. 900 lbs. 1800 lbs. 2700 lbs.
Cocktail Bar 3 lbs. ice per seat 360 lbs. 900 lbs. 1800 lbs. 3600 lbs. 5400 lbs.
Water Glass 6 oz. ice per 12 oz. glass 45 lbs. 113 lbs. 225 lbs. 450 lbs. 675 lbs.
Salad Bar 35 lbs. ice per cubic foot --- --- --- --- ---
Beverage Only 5 oz. ice per 7-10 oz. cup 38 lbs. 94 lbs. 188 lbs. 375 lbs. 563 lbs.
Beverage Only 8 oz. ice per 12-16 oz. cup 60 lbs. 150 lbs. 300 lbs. 600 lbs. 900 lbs.
Beverage Only 12 oz. ice per 18-24 oz. cup 90 lbs. 225 lbs. 450 lbs. 900 lbs. 1350 lbs.
Guest Ice 5 lbs. per hotel room 600 lbs. 1500 lbs. 3000 lbs. 6000 lbs. 9000 lbs.
Hotel Catering 1 lb. per person 120 lbs. 300 lbs. 600 lbs. 1200 lbs. 1800 lbs.
Patient Ice 10 lbs. per person 1200 lbs. 3000 lbs. 6000 lbs. 12000 lbs. 18000 lbs.
Cafeteria 1 lb. per person 120 lbs. 300 lbs. 600 lbs. 1200 lbs. 1800 lbs.

Ice Machine Bin Sizing

An ice machine bin lets you hold ice until it's ready for use. When picking a bin to go with your modular ice machine, you'll want to take several points into consideration:

    Manitowoc B-570 Ice Machine Bin 430 Pound
  • Choose a bin / machine combination that's too large, and it could result in wasted ice, making the bin a breeding ground for bacteria and mold due to excess melt water.
  • Choosing a small ice machine and bin combination might leave you running out of ice and taxing your machine as it struggles to keep up.
  • Don't assume the bin has to match the capacity of your machine. If your restaurant is busiest on the weekend, for example, you might need 900 lbs. of ice, but not nearly that much during the week. Pairing a small ice machine with a large bin will ensure you don't over-produce during the week, and that you'll still accumulate enough ice to handle the weekend rush.

You can find compatible bins in the Companion Items of most of our modular ice machines.

Filters

C Pure AQUAKING10 10 inch Single Cartridge Ice Machine Water Filtration System - 25 Micron Rating and 3 GPM

To prolong the life of your restaurant ice machine and increase your customers' satisfaction (remember, ice is food), we recommend using a water filter with every ice machine, because it will reduce the buildup of mineral deposits within the machine. The benefits of using a water filter with your unit cannot be understated, but here are just a few:

  • Better tasting beverages
  • Higher ice production
  • Lower energy usage, since the ice machine can work more efficiently
  • Longer ice machine life
  • Poor quality feed water will VOID THE WARRANTY on most ice machines

We offer two sizes of ice machine filter kits that will work with all the ice machines we carry. They are located in each machine's Companion Items.

Accessories

Ice Dispensers

An ice dispenser is similar to a bin in concept - it holds ice until use but it eliminates human contact with the ice supply by using a sensor or lever dispenser system. There are two basic types:

    Manitowoc SPA-160 Hotel Ice Dispenser 120 Pound
  • Hotel Dispensers: A modular ice machine is mounted on top and the dispenser holds the ice. This lets guests get ice at their leisure and you don't need to worry about them contaminating the ice with hands, cups, etc. We even offer several models that are coin operated, while room-key operated models ensure that only customers use your ice.

  • Follett Symphony Countertop Ice Maker and Water Dispenser Compressed Nugget Ice 12 lb. Storage 115V
  • Countertop Dispensers: These are most common at nurse stations and other healthcare applications due to their compact size, and many also dispense water, too. We offer two types, ones that include a built in ice machine and models that require the ice be loaded manually.

Bin Adapters

Bin adapters are used in several situations.

  • Installing one or more small ice machines on a big bin
  • Installing an ice machine on top of an ice dispenser
  • Installing one brand of ice machine on a different brand of ice machine bin

Keep in mind that many more types of adapters are available for very specific situations, and are often listed on the manufacturer's Specification Sheet. Depending on your application, you may also need an ice deflector in place of or in addition to the adapter.


Noble Chemical Arctic Ready To Use Ice Machine Cleaner

Ice Machine Cleaner

Even with the proper filter kit your machine will still gradually accumulate mineral deposits on the interior, harming performance and efficiency. Our Noble Chemical Arctic ice machine cleaner is safe for use in all ice machines and will remove these buildups, while also protecting tin and nickel-plated evaporators! The Arctic cleaner is available in both a concentrated cleaner and a ready to use formula.


Vizion ICE-H Heat Exchanger for Hoshizaki Ice Machines

Heat Exchangers

A heat exchanger uses cold waste water from your ice machine to pre-chill potable water entering your machine. Because the water is already cold, your unit spends less energy making ice, which cuts costs and allows more efficient operation. Compatible heat exchangers are listed in the Companion Items of our ice machines.


B-28 Kit #2 EZ Bagger Ice Bagger Kit for 8 lb. and 10 lb. Ice Bags

Ice Baggers

If you plan on selling bags of ice, a bagger kit may be a worthwhile investment. For small-volume applications, we offer frames that fit right over the ice bin door opening and funnel ice down into the bag. Or, for very large-scale use where you'll be packing and selling lots of ice, we offer units specially designed to store and load the product.


Other Must-Have Accessories

These two products go hand-in-hand. To stay in accordance with health and sanitation regulations, use these items to transport ice from the bin to other locations around your establishment, and make sure your employees use them, rather than cups or hands.
